CRANKSHAFT
/ Cummins 310
1
1
1
1
1
1
2
3
4
5
5
5A
6
6
7
8
9
10
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
34
35
36
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 87335711 | CRANKSHAFT | 1; | - | |
| 1 | 87356215 | CRANKSHAFT | 1; | - | |
| 1 | 87342925 | REMAN-CRANKSHAFT | 1; | - | |
| 1 | 87356216 | REMAN-CRANKSHAFT | 1; | - | |
| 1 | 87337253 | CORE-CRANKSHAFT | 1; | - | |
| 1 | 87356217 | CORE-CRANKSHAFT | 1; | - | |
| 2 | J918776 | GEAR | 1; | - | |
| 3 | J904483 | PIN | 1; | - | |
| 4 | SEAL | SEAL | 1; | - | |
| 5 | J925570 | DAMPER | 1; | - | |
| 5 | 87357611 | DAMPER | 1; | - | |
| 5A | 87422144 | PULLEY | 1; | - | |
| 6 | J906733 | BOLT | 4; | - | |
| 6 | J914118 | SCREW | 5; | - | |
| 7 | SEAL | SEAL | 1; | - | |
| 8 | J933384 | COVER | 1; | - | |
| 9 | J914301 | GASKET | 1; | - | |
| 10 | 87409160 | SCREW | 8; | - | |
| 11 | J945930 | BEARING | 6; | - | |
| 11 | J945931 | BEARING | 6; | - | |
| 11 | J945932 | BEARING | 6; | - | |
| 11 | J945933 | BEARING | 6; | - | |
| 11 | J945934 | BEARING | 6; | - | |
| 12 | J945929 | BEARING | 1; | - | |
| 12 | J945922 | BEARING | 1; | - | |
| 12 | J945923 | BEARING | 1; | - | |
| 12 | J945924 | BEARING | 1; | - | |
| 12 | J945925 | BEARING | 1; | - | |
| 12 | J945926 | BEARING | 1; | - | |
| 12 | J945927 | BEARING | 1; | - | |
| 12 | J945928 | BEARING | 1; | - | |
| 13 | J918113 | SHIELD | 1; | - | |
| 14 | A77790 | KIT | 1; | - | |
| 15 | SEAL | SEAL | 1; | - | |
| 16 | TOOL | TOOL | 1; | - | |
| 17 | TOOL | TOOL | 1; | - | |
| 18 | J918113 | SHIELD | 1; | - | |
| 19 | A77808 | KIT | 1; | - | |
| 20 | SLEEVE | SLEEVE | 1; | - | |
| 21 | TOOL | TOOL | 1; | - | |
| 22 | SEAL | SEAL | 1; | - | |
| 23 | J924987 | SHIELD | 1; | - | |
| 24 | J934486 | KIT | 1; | - | |
| 25 | SEAL | SEAL | 1; | - | |
| 26 | TOOL | TOOL | 1; | - | |
| 27 | A77810 | KIT | 1; | - | |
| 28 | SLEEVE | SLEEVE | 1; | - | |
| 29 | SEAL | SEAL | 1; | - | |
| 30 | 87423334 | SEAL | 1; | - | |
| 30 | 87434865 | SEAL | 1; | - | |
| 34 | 87335719 | RING | 1; | - | |
| 35 | 87335729 | BOLT | 4; | - | |
| 36 | J329899 | DOWEL | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
