ACCESSORY DRIVE
/ Cummins NT855-C280 BC III
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 3005131 | 3005131 | DRIVE, ACCESSORY | 1; | |
| 3007821 | 3007821 | MTG, ACCESSORY DRIVE | 1; | |
| BM95029 | BM95029 | PUMP, FUELMTG | 1; | |
| S911В | S911В | PLUG, PIPE | 1; | |
| AR45728 | AR45728 | HOUSING, ACCESSORY | 1; | |
| 1 | 3034438 | DOWEL, PIN | 1; | |
| 3 | 3014103 | WASHER, PLAIN | 1; | |
| 4 | 3002170 | SUPPORT, FUEL PUMP | 1; | |
| 5 | 3010590 | SCREW, CAPTIVE WAS | 5; | |
| 6 | 116391 | BUSHING | 1; | |
| 7 | 3026556 | BEARING, THRUST | 1; | |
| 8 | 3000175 | HUB, JAW COUPLING | 1; | |
| 9 | 3046200 | SPIDER, JAW COUPLING | 1; | |
| 10 | 170664 | WASHER, PLAIN | 1; | |
| 11 | 129510 | SCREW, HEXAGON HEAD CAP | 1; | |
| 12 | 3048341 | GASKET, FUEL PUMP | 1; | |
| 13 | S140 | SCREW, HEXAGON HEAD | 4; | |
| 14 | 69324 | WASHER, PLAIN | 4; | |
| 15 | S610 | WASHER, LOCK | 4; | |
| 16 | S274 | NUT, HEAVY HEXAGON | 4; | |
| 17 | 3000171 | SHAFT, ACCESSORY DRIVE | 1; | |
| 18 | 3026557 | BEARING, THRUST | 1; | |
| 19 | 142689 | GEAR, ACCESSORY DRIVE | 1; | |
| 20 | 200809 | GASKET, ACC DRIVE SUPPORT | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
