FAN IDLER
/ Cummins NT855-C280 BC III
1
2
3
4
5
5
7
8
9
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
27
28
29
30
31
32
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 3418996 | 3418996 | BRACKET, SHIPPING | 1; | |
| 3419359А | 3419359А | SHIM | 1; | |
| 3419359В | 3419359В | SHIM | 1; | |
| 3419359С | 3419359С | SHIM | 1; | |
| 3419360А | 3419360А | SHIM | 1; | |
| 3419360В | 3419360В | SHIM | 1; | |
| 3419360С | 3419360С | SHIM | 1; | |
| S911В | S911В | PLUG, PIPE | 2; | |
| 3260625 | 3260625 | BRACKET, PIVOT | 1; | |
| S622 | S622 | WASHER, PLATE | 2; | |
| 3251001 | 3251001 | SCREW, FLAT HEAD CAP | 4; | |
| 3250937 | 3250937 | HUB, FAN | 1; | |
| 3600283 | 3600283 | WASHER, PLATE | 2; | |
| 3012467 | 3012467 | WASHER, PLATE | 1; | |
| 1 | 3335066 | NUT, REGULAR HEXAGON | 2; | |
| 2 | 146163 | WASHER, PLATE | 1; | |
| 3 | 423280 | WASHER, PLATE | 1; | |
| 4 | 3325952 | BOLT, HOOK | 1; | |
| 5 | 3250956 | SPRING, TENSION | 1; | |
| 5 | 3260626 | SPRING, TENSION | 1; | |
| 7 | 217008 | ACCESSORY DRIVE | 1; | |
| 8 | 217011 | SPACER, BEARING | 1; | |
| 9 | 3250932 | ACCESSORY DRIVE | 1; | |
| 11 | 3001280 | RING, RETAINING | 1; | |
| 12 | 3655115 | BEARING, ROLLER | 2; | |
| 13 | 200307 | SEAL, OIL | 1; | |
| 14 | 3250933 | LEVER, IDLER | 1; | |
| 15 | 3655343 | BRACKET, SPRING | 1; | |
| 16 | S610 | WASHER, LOCK | 1; | |
| 17 | S108А | SCREW, HEXAGON HEAD CAP | 1; | |
| 18 | S2268 | FITTING, GREASE | 1; | |
| 19 | 3335067 | NUT, REGULAR HEXAGON | 1; | |
| 20 | S613 | SPRING WASHER | 1; | |
| 21 | 3325495 | SHAFT- PIVOT | 1; | |
| 22 | 13325107 | BEARING, NEEDLE | 1; | |
| 23 | 423260 | PLATE, CLAMP | 1; | |
| 24 | S610 | WASHER, LOCK | 1; | |
| 25 | 3335055 | SCREW, HEXAGON HEAD CAP | 1; | |
| 27 | 3011715 | SCREW, CAPTIVE WASHER CAP | 4; | |
| 28 | 3326154 | BRACKET, IDLER PULLEY | 1; | |
| 29 | 142176 | NUT, LOCK | 1; | |
| 30 | 3251000 | GASKET, COVER PLATE | 2; | |
| 31 | 3250999 | PLATE, COVER | 1; | |
| 32 | S140 | SCREW, HEXAGON HEAD | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
