CLEANER, AIR AC 1262
/ Cummins QSNT-G
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
19
20
21
22
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 4297016 | 4297016 | PLATE, CLAMPING | 1; | |
| 4297013 | 4297013 | PLATE, CLAMPING | 1; | |
| S 103 D | S 103 D | SCREW, HEX HEAD CAP | 1; | |
| S 604 | S 604 | WASHER LOCK | 4; | |
| 1 | S 106 A | SCREW, HEX HEAD CAP | 2; | |
| 2 | S 112 | SCREW HEXAGON HEAD CAP | 4; | |
| 3 | S 186 A | SCREW, HEX HEAD CAP | 2; | |
| 4 | S 221 | NUT HEAVY HEXAGON | 2; | |
| 5 | S 223 | NUT HEAVY HEXAGON | 6; | |
| 6 | S 605 | WASHER LOCK | 2; | |
| 7 | 108330 | Плоская шайба | 4; | |
| 8 | 125741 | CLAMP, T BOLT | 2; | |
| 9 | 127316 | WASHER, PLAIN | 2; | |
| 10 | 140313 | CLAMP, T BOLT | 1; | |
| 11 | 197221 | STRAP, CLEANER | 2; | |
| 12 | 3000302 | TUBE, AIR INLET | 1; | |
| 13 | 3000958 | AIR CLEANER | 1; | |
| 14 | 3013238 | CAP, AIR CLEANER | 1; | |
| 16 | 3030514 | ADAPTER | 1; | |
| 17 | 4296849 | HOSE, HUMP | 1; | |
| 18 | 3175623 | CLAMP, T BOLT | 1; | |
| 19 | 63385 | SPACER, WATER CONN | 2; | |
| 20 | 4296843 | BRACKET AIR CLEANER | 1; | |
| 21 | S 117 | SCREW HEXAGON HEAD | 2; | |
| 22 | S 602 | WASHER PLAIN | 2; |
