INJECTOR PP 44691
/ Cummins QSNT-G
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 4307776 | 4307776 | INJECTOR | 6; | |
| 3411711 | 3411711 | Barrel & Plunger | 1; | |
| 3087556 | 3087556 | BODY, INJECTOR | 1; | |
| 3083863 | 3083863 | Coupling, Injector Plunger | 1; | |
| 4307777 | 4307777 | CUP, INJECTOR | 1; | |
| 3095107 | 3095107 | LINK, INJECTOR PLUNGER | 1; | |
| 3072823 | 3072823 | Spacer, Inj Spring Housing | 1; | |
| 1 | 4077153 | Pin, Straight | 2; | |
| 2 | 3068959 | Seal, O-Ring | 1; | |
| 3 | 3070113 | Sleeve, Injector | 1; | |
| 4 | 3070136 | Seal, О Ring | 1; | |
| 5 | 3070137 | Seal, О Ring | 1; | |
| 6 | 3070138 | Seal, О Ring | 1; | |
| 7 | 3071967 | Screen, Filter | 1; | |
| 8 | 3072819 | Spacer, Inj Spring Housing | 1; | |
| 9 | 3072820 | Spring, Injector | 1; | |
| 10 | 3072821 | Guide, Spring | 1; | |
| 11 | 3072822 | Screw, Socket Set | 1; | |
| 12 | 3076068 | Ball, Check | 1; | |
| 13 | 3073244 | RETAINER, INJECTOR CUP | 1; | |
| 14 | 3411775 | SHIM | 1; | |
| 15 | 3076256 | Harness, Wiring | 1; | |
| 16 | 3411340 | SPRING, INJECTOR | 1; | |
| 17 | 3081388 | Spring, Injector | 1; | |
| 18 | 3079924 | Socket, Injector Coupling | 1; | |
| 19 | 3083862 | Coupling, Injector Plunger | 1; | |
| 20 | 3080766 | RETAINER, INJ COUPLING | 1; | |
| 21 | 3080811 | SCREW, SOCKET HEAD CAP | 2; | |
| 22 | 3075613 | Screw, Socket Head Cap | 1; | |
| 23 | 3080421 | Washer, Sealing | 1; | |
| 24 | 4307547 | VALVE, SOLENOID | 1; | |
| 25 | 3087554 | BODY & PLUNGER | 1; | |
| 26 | 3072486 | Retainer, Injector Link | 1; | |
| 27 | 3078226 | LINK, INJECTOR PLUNGER | 1; | |
| 28 | 3095088 | Barrel, Injector | 1; | |
| 29 | 3411710 | Plunger, Injector | 1; | |
| 30 | 3066736 | Housing, Injector Spring | 1; | |
| 31 | 3066738 | Spring, Compression | 1; | |
| 32 | 3067426 | Retainer, Injector Spring | 1; | |
| 33 | 4307778 | CUP, INJECTOR | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
