PUMP, WATER WP 1780
/ Cummins QSNT-G
1
2
3
4
5
6
7
8
8
8
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
21
22
23
24
25
26
27
28
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 4915398 | 4915398 | PUMP, WATER | 1; | |
| 4296121 | 4296121 | PULLEY, WATER PUMP | 1; | |
| 4914636 | 4914636 | PULLEY, IDLER | 1; | |
| 1 | 182706 | SCREW, HEXAGON HEAD | 1; | |
| 2 | 217638 | BELT, V RIBBED | 1; | |
| 3 | 3012468 | SCREW, CAPTIVE WAS | 4; | |
| 4 | 3012469 | SCREW, CAPTIVE WAS | 2; | |
| 5 | 3076522 | GASKET, WATER PUMP | 1; | |
| 6 | S 201 | NUT, HEAVY HEXAGON | 1; | |
| 7 | S 965 E | PLUG, PIPE | 1; | |
| 8 | S 16255 | RING, RETAINING | 1; | |
| 8 | S 16255 | RING, RETAINING | 1; | |
| 9 | 145506 | SAEL, O RING | 1; | |
| 10 | 213082 | WASHER, PLAIN | 1; | |
| 11 | 215397 | PULLEY, IDLER | 1; | |
| 12 | 3038998 | SEAL, OIL | 1; | |
| 13 | 3063246 | BEARING, BALL | 1; | |
| 14 | 4914655 | SHAFT, IDLER | 1; | |
| 15 | 4914656 | SPACER, MOUNTING | 1; | |
| 16 | S 911 B | PLUG, PIPE | 2; | |
| 17 | 112302 | RING, RETAINING | 1; | |
| 18 | 196844 | SPACER, BEARING | 1; | |
| 19 | 3000888 | IMPELLER, WATER PUMP | 1; | |
| 20 | 3014241 | INSERT, IMPELLER | 1; | |
| 21 | 3010150 | BEARING, IDLER BALL | 2; | |
| 22 | 3013786 | PLUG, PIPE | 1; | |
| 23 | 3038997 | SEAL, OIL | 1; | |
| 24 | 4060899 | SEAL, WATER PUMP | 1; | |
| 25 | 4296120 | SHAFT, WATER PUMP | 1; | |
| 26 | 203097 | SLEEVE, WEAR | 1; | |
| 27 | 3025861 | PULLEY, WATER PUMP | 1; | |
| 28 | 4296123 | BODY, WATER PUMP | 1; |
