PP10224 Engine Piston
/ Cummins QSX-15 I
1
2
2
3
4
5
6
7
8
9
9
10
11
12
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 4059429 | 4059429 | Rod, Engine Connecting | 6; | |
| 4925971 | 4925971 | Bearing, Connecting Rod | 6; | |
| 4925975 | 4925975 | Bearing, Connecting Rod | 6; | |
| 4089406 | 4089406 | Set, Piston Ring | 6; | |
| 3682398 | 3682398 | Ring, Oil Piston | 1; | |
| 3683008 | 3683008 | Ring, Compression Piston | 1; | |
| 3681078 | 3681078 | Ring, Compression Piston | 1; | |
| 4089895 | 4089895 | Kit, Engine Piston | 6; | |
| 3064305 | 3064305 | Ring, Retaining | 2; | |
| 4923744 | 4923744 | Piston, Engine | 1; | |
| 4923748 | 4923748 | Pin, Piston | 1; | |
| 4089405 | 4089405 | Set, Rod Bearing | 6; | |
| 4089406 | 4089406 | Set, Piston Ring | 1; | |
| 1 | 4059449 | Rod, Engine Connecting | 6; | |
| 2 | 3678574 | Screw, Connecting Rod Cap | 4; | |
| 3 | 3678739 | Dowel, Ring | 2; | |
| 4 | 4059448 | Bushing | 1; | |
| 5 | 4925971 | Bearing, Connecting Rod | 6; | |
| 6 | 4925975 | Bearing, Connecting Rod | 6; | |
| 7 | 4923748 | Pin, Piston | 6; | |
| 8 | 4923744 | Piston, Engine | 6; | |
| 9 | 3064305 | Ring, Retaining | 12; | |
| 10 | 3684010 | Ring, Compression Piston | 6; | |
| 11 | 3681078 | Ring, Compression Piston | 6; | |
| 12 | 3682398 | Ring, Oil Piston | 6; |
