FA2164-08 Fan Drive
/ Cummins Серия ISMe
/27.gif)
1
2
3
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
22
23
24
25
26
27
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 3065358 | 3065358 | Hub, Fan | 1; | - | |
| FA2164-08 | FA2164-08 | Fan Drive | ; | - | |
| 3892768 | 3892768 | Pulley, Idler | 1; | - | |
| 3062602 | 3062602 | Pulley, Idler Tla | ; | - | |
| 1 | S117 | SCREW, HEXAGON HEAD CAP | 2; | - | |
| 2 | 107695 | Pin, Roll | 1; | - | |
| 3 | 3009330 | Washer, Plain | 2; | - | |
| 5 | 3288576 | Belt, V Ribbed | 1; | - | |
| 6 | 3034319 | Nut, Regular Hexagon | 1; | - | |
| 7 | 3034320 | Washer, Plain | 1; | - | |
| 8 | 3034836 | Screw, Hexagon Head Cap | 4; | - | |
| 9 | 3046206 | Pulley, Fan | 1; | - | |
| 10 | 3060884 | Cover, Idler Pulley | 1; | - | |
| 11 | 3062601 | Seal, O-Ring | 1; | - | |
| 12 | 3003163 | Washer, Plain | 1; | - | |
| 13 | 3027680 | Seal, Oil | 1; | - | |
| 14 | 3027681 | Bearing, Roller | 1; | - | |
| 15 | 3060883 | Pulley, Idler | 1; | - | |
| 16 | 3335044 | Screw, Hexagon Head Cap | 1; | - | |
| 17 | 3819920 | Shaft, Idler | 1; | - | |
| 18 | 3027675 | Seal, Oil | 1; | - | |
| 19 | 3027676 | Shaft, Fan Hub | 1; | - | |
| 20 | 3027677 | Flange | 1; | - | |
| 21 | 3027686 | Washer, Plain | 1; | - | |
| 22 | 3037597 | Hub, Fan | 1; | - | |
| 23 | 3063844 | Cover, Fan Hub | 1; | - | |
| 24 | 3896996 | Bearing, Roller | 1; | - | |
| 25 | 3081348 | Screw, Hexagon Head Cap | 3; | - | |
| 26 | 3253776 | Support, Fan | 1; | - | |
| 27 | 3253778 | Screw, Hexagon Head Cap | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
