OP 9352 Oil Pan
/ DCEC 6CTA8.3-C190-II
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | C3900628 | SCREW, HEX FLANGE HEAD CA | 2; | |
| 2 | C3901865 | SCREW, HEX FLANGE HEAD CA | 1; | |
| 3 | C3902425 | WASHER, SEALING | 1; | |
| 4 | C3906216 | NUT, HEXAGON FLANGE | 1; | |
| 5 | C3910787 | CONNECTION, OIL SUCTION | 1; | |
| 6 | C3910960 | WASHER, PLAIN | 1; | |
| 7 | C3913638 | SCREW, HEX FLANGE HEAD CA | 2; | |
| 8 | C3914013 | PAN, OIL | 1; | |
| 9 | C3920400 | SCREW, HEX FLANGE HEAD CA | 32; | |
| 10 | C3920773 | WASHER, SEALING | 1; | |
| 11 | C3924147 | PLUG, THREADED | 1; | |
| 12 | C3924148 | PLUG, THREADED | 1; | |
| 13 | C3926865 | SPACER, MOUNTING | 2; | |
| 14 | C3927611 | BRACE, TUBE | 1; | |
| 15 | C3939352 | GASKET, OIL SUC CONNECTIO | 1; | |
| 16 | C3973509 | GASKET, OIL PAN | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
