Air compressor cooling water pipe
/ DCEC ISZ450 41
1
2
3
4
5
6
7
8
9
10
11
12
13
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | C108722 | CLIP | 2; | |
| 2 | C108722 | CLIP | 1; | |
| 3 | C3678873 | PLUG, THREADED | 1; | |
| 4 | C3900630 | SCREW, HEX FLANGE HEAD CA | 1; | |
| 5 | C3903990 | SCREW, HEX FLANGE HEAD CA | 1; | |
| 6 | C3921742 | SCREW, HEX FLANGE HEAD CA | 1; | |
| 7 | C4365688 | CONNECTOR, QCK DISCONNECT | 1; | |
| 8 | C4365823 | TUBE, CPR WATER OUTLET | 1; | |
| 9 | C4366010 | TUBE, CPR WATER OUTLET | 1; | |
| 10 | C4975343 | UNION, MALE | 1; | |
| 11 | C4999903 | UNION, MALE | 1; | |
| 12 | C4999912 | TUBE, CPR WATER INLET | 1; | |
| 13 | C5472286 | UNION, MALE | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
