Crankshaft
/ Deutz LKSR
1
1
2
3
4
4
5
5
6
7
9
10
11
12
13
14
15
16
17
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 99871.145.115.5 | Flywheel with gear ring | 1; | - | |
| 1 | 99871.145.015.4 | Flywheel | 1; | - | |
| 2 | 99871.375.003.4 | Gear wheel | 1; | - | |
| 3 | 60220.20.0.8018 | Dowel | 1; | - | |
| 4 | 99871.420.003.5 | Bearing bracket | 1; | - | |
| 4 | 99871.420.005.5 | Bearing bracket | ; | - | |
| 5 | 99871.420.003.4 | Bearing bracket | 1; | - | |
| 5 | 99871.420.005.4 | Bearing bracket | 1; | - | |
| 6 | 101.069.00.00 | Gasket | 1; | - | |
| 7 | 91322.24.6.2012 | Roller bearing | 1; | - | |
| 9 | 69870.670.001.4 | Counter-weight | 2; | - | |
| 10 | 60216.03.0.0100 | Spring washer | 4; | - | |
| 11 | 60200.70.0.1045 | Cheese head screw | 4; | - | |
| 12 | 69870.432.001.4 | Bearing bush | 1; | - | |
| 13 | 60220.15.0.0416 | Clampнng sleevee | 1; | - | |
| 14 | 69870.433.002.4 | Bearing ring | 1; | - | |
| 15 | 101.061.05.00 | Front gear wheel | 1; | - | |
| 16 | 99871.620.001.5 | Support with governor weig | 1; | - | |
| 17 | 60216.01.0.0060 | Lock washer | 4; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
