Fuel tank installation
/ Deutz LKSR
1
2
3
4
4
5
6
7
8
8
9
9
9
9
10
12
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 93021.976.001.5 | Tank cover | 1; | |
| 2 | 93021.850.002.4 | Gasket | 1; | |
| 3 | 6.0210.15.0.0008 | Locking nut | 2; | |
| 4 | 63214.340.002.4 | Washer | 6; | |
| 5 | 99871.960.006.5 | Fuel tank | 1; | |
| 6 | 60200.01.0.0855 | Hexagon screw | 1; | |
| 7 | 99871.703.801.4 | Vibration damper | 1; | |
| 8 | 60200.05.0.0815 | Hexagon screw | 5; | |
| 9 | 60216.01.0.0080 | Lock washer | 10; | |
| 10 | 60650.01.0.0004 | Vibration damper | 2; | |
| 12 | 60200.05.0.0820 | Hexagon screw | 2; | |
| 14 | 60210.05.4.0080 | Hexagon nut | 2; | |
| 15 | 60404.32.0.0023 | Hollow screw | 1; | |
| 16 | 99871.355.007.4 | Connection | 1; | |
| 17 | 90001.939.001.4 | Flexible pipe | 1; | |
| 18 | 99871.653.004.4 | Sopport | 1; | |
| 19 | 60492.01.0.0811 | Packing ring | 2; | |
| 20 | 90001.939.002.4 | Flexible pipe | 1; | |
| 21 | 99871.740.004.4 | Fuel filter | 1; | |
| 22 | 99871.939.009.4 | Flexible pipe | 1; | |
| 23 | 90001.939.002.4 | Flexible pipe | 1; | |
| 24 | 91401.51.0.0013 | Collar band | 4; | |
| 25 | 99871.977.005.4 | Collar band | 1; | |
| 26 | 99871.765.001.5 | Air valve | 1; | |
| 27 | 60492.01.0.1216 | Packing ring | 2; | |
| 28 | 99871.653.008.4 | Sopport | 1; | |
| 29 | 63240.330.023.4 | Bush | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
