Turbocharger
/ Doosan DP180LB
1
2
3
3
4
4
5
5
6
6
7
7
8
9
10
11
11
12
12
13
14
15
16
17
18
19
20
20
21
21
22
22
23
23
24
24
24
25
25
26
26
27
| Поз. | Артикул | Название детали | DP180LAF | DP180LAS | DP180LBF | DP180LBS | |
|---|---|---|---|---|---|---|---|
| 1 | 150105-00582 | Turbocharger assy | 1 | 1 | 1 | 1 | |
| 2 | 150105-00583 | Turbocharger assy | 1 | 1 | 1 | 1 | |
| 3 | 65.09901-0033 | Gasket | 2 | 2 | 2 | 2 | |
| 4 | 65.90201-0076 | Bolt | 8 | 8 | 8 | 8 | |
| 5 | 65.90535-0001 | Nut | 8 | 8 | 8 | 8 | |
| 6 | 65.08901-0063 | Gasket | 2 | 2 | 2 | 2 | |
| 7 | 06.06226-0808 | Bolt | 12 | 12 | 12 | 12 | |
| 8 | 420214-00249 | Pipe | 1 | 1 | 1 | 1 | |
| 9 | 65.97401-0110A | Clip | 1 | 1 | 1 | 1 | |
| 10 | 420214-00374 | Pipe | 1 | 1 | 1 | 1 | |
| 11 | 65.96601-0046B | Gasket | 2 | 2 | 2 | 2 | |
| 12 | 06.01913-3114 | Bolt | 4 | 4 | 4 | 4 | |
| 13 | 65.91701-0086 | Spacer | 1 | 1 | 1 | 1 | |
| 14 | 06.01913-3124 | BOLT ASS'Y M8X65 | 1 | 1 | 1 | 1 | |
| 15 | 110928-00360 | Holder | 1 | 1 | 1 | 1 | |
| 16 | 65.97401-0110A | Clip | 1 | 1 | 1 | 1 | |
| 17 | 06.01923-3112 | Bolt | 1 | 1 | 1 | 1 | |
| 18 | 06.56190-0706 | Ring | 3 | 3 | 3 | 3 | |
| 19 | 65.98150-0071 | Screw | 1 | 1 | 1 | 1 | |
| 20 | 65.96601-0067 | Gasket | 2 | 2 | 2 | 2 | |
| 21 | 420217-00227 | Pipe | 2 | 2 | 2 | 2 | |
| 22 | 06.01913-3114 | Bolt | 4 | 4 | 4 | 4 | |
| 23 | 420107-00301 | Hose | 2 | 2 | 2 | 2 | |
| 24 | 65.97440-0103 | Clamp | 4 | 4 | 4 | 4 | |
| 25 | 65.98131-0071 | Screw | 2 | 2 | 2 | 2 | |
| 26 | 06.56190-0728 | Ring | 2 | 2 | 2 | 2 | |
| 27 | 06.01913-3217 | Bolt | 1 | 1 | 1 | 1 |
