Fuel Pipe
/ Doosan P158FE
/42.gif)
1
2
3
4
4
4
4
5
5
5
5
6
6
6
6
7
7
8
8
8
8
9
9
10
10
11
12
13
13
13
14
14
14
15
16
17
18
19
19
20
20
21
22
23
24
25
26
27
27
28
| Поз. | Артикул | Название детали | P158FE-EUZOA | P158FE-EUZOB | Цена | |
|---|---|---|---|---|---|---|
| 1 | 65.96340-5016 | Hose | 1 | 1 | - | |
| 2 | 65.96340-5017 | Hose | 1 | 1 | - | |
| 3 | 65.98130-0202 | Adapter | 1 | 1 | - | |
| 4 | 06.78144-2204 | Screw | 5 | 5 | - | |
| 5 | 06.56190-0706 | Ring | 8 | 8 | - | |
| 6 | 65.96507-0043 | Ring | 3 | 3 | - | |
| 7 | 65.12301-5278 | Pipe | 2 | 2 | - | |
| 8 | 65.96507-0055 | Ring | 8 | 8 | - | |
| 9 | 65.98150-0042A | Screw | 6 | 6 | - | |
| 10 | 65.98130-0155 | Adapter | 2 | 2 | - | |
| 11 | 65.96341-0109 | Hose | 1 | 1 | - | |
| 12 | 65.98101-0027 | Union | 1 | 1 | - | |
| 13 | 65.98150-0042A | Screw | 3 | 3 | - | |
| 14 | 65.96507-0055 | Ring | 3 | 3 | - | |
| 15 | 06.78144-2204 | Screw | 1 | 1 | - | |
| 16 | 06.56190-0706 | Ring | 2 | 2 | - | |
| 17 | 65.97460-0001 | Band | 4 | 4 | - | |
| 18 | 65.96340-5075 | Hose | 1 | 1 | - | |
| 19 | 65.98130-0154 | Adapter | 8 | 8 | - | |
| 20 | 06.56180-0712 | Ring | 8 | 8 | - | |
| 21 | 65.12540-5032 | Bracket | 1 | 1 | - | |
| 22 | 65.12501-7036 | Fuel filter assy | 1 | 1 | - | |
| 23 | 06.01923-2912 | Bolt | 4 | 4 | - | |
| 24 | 06.08092-2406 | Screw | 1 | 1 | - | |
| 25 | 06.56190-0712 | Ring | 1 | 1 | - | |
| 26 | 06.78190-0206 | Screw | 1 | 1 | - | |
| 27 | 06.56190-0706 | Ring | 2 | 2 | - | |
| 28 | 06.08092-2404 | Screw | 1 | 1 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
