Turbo Charger
/ Doosan P180FE
/32.gif)
1
2
3
3
4
4
5
5
6
6
7
7
8
9
10
10
11
11
12
12
13
13
14
14
14
15
16
17
18
18
18
19
20
21
22
23
24
24
25
25
25
25
26
26
27
27
28
29
| Поз. | Артикул | Название детали | P158FE-EUZOA | P158FE-EUZOB | Цена | |
|---|---|---|---|---|---|---|
| 1 | 65.09100-7048 | Charger | 1 | 1 | - | |
| 2 | 65.09100-7049 | Charger | 1 | 1 | - | |
| 3 | 65.09901-0018A | GASKET | 2 | 2 | - | |
| 4 | 65.90201-0073 | Bolt | 8 | 8 | - | |
| 5 | 65.90535-0001 | Nut | 8 | 8 | - | |
| 6 | 65.09901-0012 | Gasket | 2 | 2 | - | |
| 7 | 06.06226-0806 | Bolt | 12 | 12 | - | |
| 8 | 65.05701-5208 | Pipe | 1 | 1 | - | |
| 9 | 65.05701-5286B | Pipe | 1 | 1 | - | |
| 10 | 65.98131-5003 | Adapter flange assy | 2 | 2 | - | |
| 11 | 65.96601-0046B | Gasket | 2 | 2 | - | |
| 12 | 06.02090-0410 | Bolt | 4 | 4 | - | |
| 13 | 06.78144-2403 | Screw | 2 | 2 | - | |
| 14 | 06.56190-0704 | Ring | 4 | 4 | - | |
| 15 | 65.98130-0079 | Adapter | 1 | 1 | - | |
| 16 | 06.56190-0705 | Ring | 1 | 1 | - | |
| 17 | 65.98150-0031 | Screw | 1 | 1 | - | |
| 18 | 06.56190-0704 | Ring | 3 | 3 | - | |
| 19 | 65.05701-5207 | Pipe | 1 | 1 | - | |
| 20 | 65.05701-5206 | Pipe | 1 | 1 | - | |
| 21 | 65.05701-5175 | Pipe | 1 | 1 | - | |
| 22 | 65.98130-0068 | Adapter | 1 | 1 | - | |
| 23 | 06.56190-0728 | Ring | 1 | 1 | - | |
| 24 | 65.96301-0382 | Hose | 2 | 2 | - | |
| 25 | 06.67020-0106 | Clamp | 4 | 4 | - | |
| 26 | 65.96601-0067 | Gasket | 2 | 2 | - | |
| 27 | 06.01913-3114 | Bolt | 4 | 4 | - | |
| 28 | 65.91701-0031 | Spacer | 1 | 1 | - | |
| 29 | 06.01923-3120 | Bolt | 1 | 1 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
