Alternator Mounting
/ Doosan P180LE
1
2
2
3
3
4
5
6
7
8
9
10
11
12
12
13
14
| Поз. | Артикул | Название детали | P180LE-EASOA | P180LE-EASOC | P180LE-EASQA | P180LE1-EASOB | P180LE1-EASQB | P180LES-EASOE | P180LES-EASOF | P180LES-EASQE | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 65.19102-0071 | Bracket | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 2 | 06.01284-7420 | Bolt | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | |
| 3 | 06.16731-2110 | Washer | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | |
| 4 | 65.90001-0002A | Bolt | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 5 | 06.15010-2313 | Washer | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 6 | 06.16731-2109 | Washer | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 7 | 06.11063-9216 | Nut | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 8 | 65.90441-0061 | Bolt | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 9 | 65.19107-0005 | Piece | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 10 | 06.01913-3221 | Bolt | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 11 | 06.11063-8215 | Nut | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 12 | 06.11063-8216 | Nut | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | |
| 13 | 65.91701-0535 | Spacer | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| 14 | 06.01913-3228 | Bolt | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
