Intake Manifold
/ Doosan P180LE
1
1
2
2
3
3
4
5
6
7
8
8
8
9
10
11
11
12
12
13
13
13
13
14
15
15
16
16
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
20
20
20
20
21
21
21
21
22
22
22
22
23
23
23
23
24
24
24
24
25
26
27
27
28
28
29
29
| Поз. | Артикул | Название детали | P180LE-EASOA | P180LE-EASOC | P180LE-EASQA | P180LE1-EASOB | P180LE1-EASQB | P180LEII-EASOD | P180LES-EASOE | P180LES-EASOF | P180LES-EASQE | Цена | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 65.08201-5033 | Manifold | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 2 | 65.08902-0078D | Gasket | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | - | |
| 3 | 06.01923-3132 | Bolt | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | - | |
| 4 | 65.08203-0008 | Cover | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 5 | 65.09411-5045 | Inlet | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 6 | 65.09411-0059 | Inlet | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 7 | 65.09411-0060 | Inlet | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 8 | 65.08902A0082 | Gasket | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | - | |
| 9 | 06.01913-3112 | BOLT ASS'Y M8X18 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | - | |
| 10 | 06.01013-9127 | Bolt | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 11 | 06.01013-9132 | Bolt | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 12 | 65.96301-0267 | Hose | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 13 | 06.67020-0112 | Clamp | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 14 | 65.08202-0102 | Stake | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 15 | 65.96301-0272 | Hose | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 16 | 65.97440-0096 | Clamp | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 17 | 65.09411-0064 | Inlet | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 18 | 65.96301-0270 | Hose | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 19 | 65.97440-5005 | Clamp | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | - | |
| 20 | 65.97401-0166 | Clip | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 21 | 65.91701-0205 | Spacer | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 22 | 06.01013-9131 | Bolt | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 23 | 06.16731-2107 | Washer | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 24 | 06.15010-2311 | Washer | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 25 | 65.09411-0089 | Inlet | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 26 | 65.09411-0088 | Inlet | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 27 | 65.09905-0004 | Gasket | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 28 | 06.01953-3318 | Bolt | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | - | |
| 29 | 65.96301-0329 | Hose | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
