Exhaust Manifold
/ Doosan P222LE
1
2
2
3
4
5
5
6
6
7
7
7
8
9
9
10
11
12
12
13
13
14
14
14
15
16
17
17
18
18
18
19
19
20
20
21
22
23
23
24
24
25
25
26
26
27
27
27
27
| Поз. | Артикул | Название детали | P222LE-EAYOA | P222LE-EAYOC | P222LE-EAYQA | P222LE1-EAYOB | P222LEII-EAYOD | P222LES-EAYOE | P222LES-EAYOF | P222LES-EAYQE | Цена | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 65.08100-6080 | Exhaust manifold assy | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 2 | 65.08101-0252 | Manifold | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 3 | 65.08101-0253 | Manifold | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 4 | 65.08901-0060 | Gasket | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 5 | 65.90001-0157 | Bolt | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 6 | 65.90801-0013 | Washer | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 7 | 65.90701-0054 | Washer | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 8 | 65.08100-6079 | Exhaust manifold assy | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 9 | 65.08101-0249 | Manifold | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 10 | 65.08101-0250 | Manifold | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 11 | 65.08901-0060 | Gasket | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 12 | 65.90001-0157 | Bolt | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 13 | 65.90801-0013 | Washer | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 14 | 65.90701-0054 | Washer | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 15 | 65.08101-0248 | Manifold | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 16 | 65.08101-0251 | Manifold | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 17 | 65.98701-0005 | Ring | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 18 | 65.08901-0023B | Gasket | 12 | 12 | 12 | 12 | - | |||||
| 18 | 65.08901-0040 | Gasket | 12 | 12 | 12 | 12 | - | |||||
| 19 | 65.90001-0156 | Bolt | 24 | 24 | 24 | 24 | 16 | 16 | 16 | 16 | - | |
| 20 | 65.91701-0541 | Spacer | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | - | |
| 21 | 65.08120-5046 | Screen | 1 | 1 | 1 | 1 | - | |||||
| 22 | 65.08120-5047 | Screen | 1 | 1 | 1 | 1 | - | |||||
| 23 | 65.90001-0155A | Bolt | 8 | 8 | 8 | 8 | - | |||||
| 24 | 65.97480-5016 | Holder | 4 | 4 | 4 | 4 | - | |||||
| 25 | 06.16731-2108 | Washer | 8 | 8 | 8 | 8 | - | |||||
| 26 | 06.11063-8215 | Nut | 8 | 8 | 8 | 8 | - | |||||
| 27 | 65.90020-0068 | Bolt | 16 | 16 | 16 | 16 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
