Turbo Charger
/ Doosan P222LE
1
2
3
3
3
4
4
5
5
6
6
7
7
8
9
10
11
12
12
13
13
13
13
14
15
15
15
16
17
18
19
19
20
20
21
22
23
23
24
24
24
24
25
25
26
26
| Поз. | Артикул | Название детали | P222LE-EAYOA | P222LE-EAYOC | P222LE-EAYQA | P222LE1-EAYOB | P222LEII-EAYOD | P222LES-EAYOE | P222LES-EAYOF | P222LES-EAYQE | Цена | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 65.09100-7053 | Turbo charger assy | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 2 | 65.09100-7052 | Turbo charger assy | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 3 | 65.08901-0034 | Gasket | 2 | 2 | 2 | 2 | - | |||||
| 3 | 65.09901-0033 | Gasket | 2 | 2 | 2 | 2 | - | |||||
| 4 | 65.90201-0143 | Bolt | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | - | |
| 5 | 65.90535-0001 | Nut | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | - | |
| 6 | 65.08901-0063 | Gasket | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 7 | 65.90201-0076 | Bolt | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | - | |
| 8 | 65.05701-6081 | Pipe | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 9 | 65.97401-0110A | Clip | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 10 | 65.91701-0086 | Spacer | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 11 | 65.05701-6108 | Pipe | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 12 | 65.96601-0046A | Gasket | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 13 | 06.01913-3114 | Bolt | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | - | |
| 14 | 65.98103-0024A | Union | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 15 | 06.56190-0706 | Ring | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | - | |
| 16 | 06.01913-3122 | Bolt | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 17 | 65.98150-0044B | Screw | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 18 | 65.90710-0250A | Spacer | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 19 | 06.56190-0728 | Ring | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 20 | 65.96601-0045A | GASKET | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 21 | 65.05701-5672 | Pipe | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 22 | 65.05701-5673 | Pipe | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 23 | 65.96301-0382 | Hose | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 24 | 06.67020-0106 | Clamp | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 25 | 65.05701-5671 | Pipe | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 26 | 65.98130-0068 | Adapter | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
