Oil pump
/ FAW CA498
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
22
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 1011023-CB53 | Driven shaft | 1; | |
| 2 | 1011031-4X4 | Driven gear bushing | 1; | |
| 3 | 1011032-CB53 | Driven gear | 1; | |
| 4 | 1011022-X2 | Rubber sealing ring | 1; | |
| 5 | 1011024-X2 | Pump cover | 1; | |
| 6 | CQ1480820A | Combination bolt | 5; | |
| 7 | 1011014-C012 | Transmission gear | 1; | |
| 8 | 1011026-X2 | Locating pin | 1; | |
| 9 | 1011016-X2 | Drive gear | 1; | |
| 10 | 1011013-4X4 | Drive shaft | 1; | |
| 11 | 1011021-X2 | Bushing | 1; | |
| 12 | 1011042-X2 | Spring plate | 1; | |
| 13 | 1011046-X2 | Sealing spacer-pressure relief valve | 1; | |
| 14 | 1011044-X2 | Spring- pressure relief valve | 1; | |
| 15 | 1011043-X2 | Plunger | 1; | |
| 16 | 1011047-X2 | Sealing ring | 2; | |
| 17 | CQ1460825 | Болт | 3; | |
| 18 | 1011041-X2 | Valve block | 1; | |
| 19 | CQ1460850 | Combination bolt | 1; | |
| 20 | 1011048-X2 | Tapered screw plug | 1; | |
| 21 | 1011010-CB53 | Oil pump assembly | 1; | |
| 22 | 1011040-X2 | Pressure relief valve assembly | 1; |
