Crankshaft and Flywheel
/ FAW CA4DF2
1005010-580-0000
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
23
24
24
25
26
27
28
29
30
30
31
| Поз. | Артикул | Название детали | CA4DF2-14D-YFD10, | CA4DF2-14D-YFD10W, | CA4DF2-12D-YFD10, | Цена | |
|---|---|---|---|---|---|---|---|
| 1005010-580-0000 | 1005010-580-0000 | Crankshaft assy | 1 | 1 | 1 | - | |
| 1 | 1005123-001-0000 | Bolt-damper | 11 | 11 | 11 | - | |
| 2 | 1005168-001-0000 | Washer-damper assy | 5 | 5 | 5 | - | |
| 3 | 1005190-531-YFD10 | Shock absorber assembly | 1 | 1 | 1 | - | |
| 4 | 1005050-001-0000 | Front oil seal | 1 | 1 | 1 | - | |
| 5 | 1005057-001-0000 | Oil retainer-front oil seal | 1 | 1 | 1 | - | |
| 6 | Q150B1230 | Болт с шестигранной головкой | 3 | 3 | 3 | - | |
| 7 | Q40312 | Пружинная шайба | 3 | 3 | 3 | - | |
| 8 | Q40112 | Пружинная шайба | 3 | 3 | 3 | - | |
| 9 | 1005055A001-0000 | Front oil seal seat assy | 1 | 1 | 1 | - | |
| 10 | 1005036A001-0000 | Oil retainer-crankshaft | 1 | 1 | 1 | - | |
| 11 | Q73431145 | О-образное резиновое уплотнительное кольцо | 1 | 1 | 1 | - | |
| 12 | 1005067B001-0000 | Rear oil seal seat | 1 | 1 | 1 | - | |
| 13 | Q40108 | Шайба | 5 | 5 | 5 | - | |
| 14 | Q40308 | Пружинная шайба | 5 | 5 | 5 | 10 ₽ - 60 ₽ | |
| 15 | Q150B0820 | Болт с шестигранной головкой | 5 | 5 | 5 | - | |
| 16 | 1005060A001-0000Q | Rear oil seal | 1 | 1 | 1 | - | |
| 17 | 1005124A001-0000 | Gasket-blot of flywheel | 3 | 3 | 3 | - | |
| 18 | 1005121-531-YFD10 | Flywheel | 1 | 1 | 1 | - | |
| 19 | 1005122-001-0000 | Gear ring- flywheel | 1 | 1 | 1 | - | |
| 20 | 1005037B051-0000 | Timing gear | 1 | 1 | 1 | - | |
| 21 | 1005038-051-0000 | Oil pump gear | 1 | 1 | 1 | - | |
| 22 | 1005129-001-0000 | Dowel pin-flywheel | 1 | 1 | 1 | - | |
| 23 | 1005181-001-0000 | Упорный подшипник | 3 | 3 | 3 | - | |
| 24 | 1005172-470-0000A | Main bearing shell, lower half | 5 | 5 | - | ||
| 24 | 1005172-470-0000D | Main bearing shell, lower half | 5 | 5 | 5 | - | |
| 25 | 1005014-155-0000 | Crankshaft | 1 | 1 | 1 | - | |
| 26 | GB/T119-1986 D8x20 | Straight pin | 1 | 1 | 1 | - | |
| 27 | Q150B1432 | Hexagon-headed bolt | 2 | 2 | 2 | - | |
| 28 | Q40314 | Пружинная шайба | 2 | 2 | 2 | - | |
| 29 | Q40114 | Шайба | 2 | 2 | 2 | - | |
| 30 | 1005171-470-0000A | Main bearing shell, upper half | 5 | 5 | - | ||
| 30 | 1005171-470-0000D | Main bearing shell, upper half | 5 | 5 | 5 | - | |
| 31 | 1005031-001-0000 | Фиксирующий штифт - ведущая шестерня | 1 | 1 | 1 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
