Fuel Piping
/ FAW CA4DF2
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
16
17
18
18
19
20
21
| Поз. | Артикул | Название детали | CA4DF2-14D-YFD10, | CA4DF2-14D-YFD10W, | CA4DF2-12D-YFD10, | |
|---|---|---|---|---|---|---|
| 1 | 1129010-531-YFD10 | 1st cylinder high pressure fuel pipe assembly | 1 | 1 | 1 | |
| 2 | 1129015-531-YFD10 | 2ed cylinder high pressure fuel pipe assembly | 1 | 1 | 1 | |
| 3 | 1129020-531-YFD10 | 3rd cylinder high pressure fuel pipe assembly | 1 | 1 | 1 | |
| 4 | 1129025-531-YFD10 | 4th cylinder high pressure fuel pipe assembly | 1 | 1 | 1 | |
| 5 | 1104052-400-0000 | Hollow screw | 4 | 4 | 4 | |
| 6 | Q/WC3403-1994 | Медная прокладка | 8 | 8 | 8 | |
| 7 | 1104050-105-0000 | Fuel injector leak-off pipe clamp | 1 | 1 | 1 | |
| 8 | 1104058-101-0000 | Fuel injector leak-off pipe clamp | 1 | 1 | 1 | |
| 9 | 1117000-104-0020 | Fuel filter assembly | 1 | 1 | 1 | |
| 10 | Q150B0825 | Болт М8х25 | 2 | 2 | 2 | |
| 11 | Q40108 | Шайба | 2 | 2 | 2 | |
| 12 | Q40308 | Пружинная шайба | 4 | 4 | 4 | |
| 13 | 1104030-531-YFD10 | Fuel deliver flexible pipe assembly | 1 | 1 | 1 | |
| 14 | 1104040-531-YFD10 | Fuel deliver flexible pipe assembly | 1 | 1 | 1 | |
| 15 | 1104060-520-0000 | Lubricating oil pipe assembly | 1 | 1 | 1 | |
| 16 | 1104100-001-ND6N | Oil pressure alarm sensor | 1 | 1 | 1 | |
| 16 | Q618B01 | Резьбовая заглушка | ||||
| 17 | 1104067-001-0010 | Hollow screw | 1 | 1 | 1 | |
| 18 | Q/WC3403-1994 | Медная прокладка | 3 | 3 | 3 | |
| 19 | 1104069-300-0000 | Joint | 1 | 1 | 1 | |
| 20 | 1129051-300-0000 | High pressure fuel pipe clamp lower piece | 2 | 2 | 2 | |
| 21 | 1129052-300-0000 | Rubber clamp pad | 4 | 4 | 4 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
