Water tank (radiator)
/ FAW CA4DF2

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: Water tank (radiator) / FAW CA4DF2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
16
16
16
16
17
18
19
20
21
22
23
24
25
26
27
Поз. Артикул Название детали CA4DF2-14D-YFD10, CA4DF2-14D-YFD10W, CA4DF2-12D-YFD10, Цена
1 1660320 B-worm drive type hose clamp 222 -
2 Y4DF12D10-070005 Pipe air 111 -
3 946173 Hexagon-headed bolt 222 -
4 945408 Hexagon nut, style I 222 -
5 Y4DF09D10-070001 Radiator pull rod 111 -
6 945408 Hexagon nut, style I 222 -
7 960148 Washer 222 -
8 Y4DX65D10-070004 Radiator pull rod bumper 111 -
9 Y4DF12D10-070100-1 Radiator 111 -
10 943479 B-worm drive type hose clamp 222 -
11 Y4DF09D10-070004 Water inlet 111 -
12 943482 B-worm drive type hose clamp 222 -
13 3832458 Pipe air 111 -
14 Y4DF12D10-070006 Pipe air 111 -
15 Y4DX65D10-070007 Radiator bumper 444 -
16 Y4DF12D10-070205 Left Radiator support 111 -
16 Y4DF12D10-070201 Right Radiator support 111 -
16 Y4DF12D10-070204 Right Radiator support 111 -
16 Y4DF09D10-070303 Radiator bottom case 111 -
16 Y4DF12D10-070202 Left Radiator support 111 -
16 Y4DF12D10-070200 Radiator support assy 111 -
17 945408 Hexagon nut, style I 888 -
18 942304 Washer 888 -
19 971095 Hexagon-headed bolt 444 -
20 960148 Washer 444 -
21 971095 Hexagon nut, style I 444 -
22 943479 B-worm drive type hose clamp 222 -
23 Y4DF09D10-070003 Water outlet 111 -
24 943479 B-worm drive type hose clamp 222 -
25 DHP-0042-19 Pipe air 111 -
26 943470 B-worm drive type hose clamp 222 -
27 943367 Pipe 111 -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
