Common rail system
/ FAW CA 4DC2-10E4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
19
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | Q40314 | Пружинная шайба | 1; | - | |
| 2 | CQ34114 | Гайка | 1; | - | |
| 3 | 1111216-55D | Injection pump gear | 1; | - | |
| 4 | 1112306-26E | Injection sealing gasket | 4; | - | |
| 5 | 1112013-55D | O-ring | 4; | - | |
| 6 | 1104050-26E | Fuel return pipe assy | 1; | - | |
| 7 | 1112010-26E | Injector assy | 4; | - | |
| 8 | 1112031-55D | Injector pressing plate | 4; | - | |
| 9 | 1112022-X2 | Ball washer | 4; | - | |
| 10 | 1112033-55D | Injector pressing plate bolt | 4; | - | |
| 11 | 1129010-26E | Fuel injection line for cylinder 1 assy | 1; | - | |
| 12 | 1129020-26E | Fuel injection line for cylinder 2 assy | 1; | - | |
| 13 | 1129030-26E | Fuel injection line for cylinder 3 assy | 1; | - | |
| 14 | 1129040-26E | Fuel injection line for cylinder 4 assy | 1; | - | |
| 15 | S1128010-26E | Common rail assy | 1; | - | |
| 16 | S1117010-C697 | Fuel filter assembly | 1; | - | |
| 17 | S1104040-C310 | Fuel pipe- fuel filter to pump | 1; | - | |
| 18 | CQ1460825 | Болт | 2; | - | |
| 19 | 1128032-26E | Common rail bracket 2 | 1; | - | |
| 19 | 1128031-26E | Common rail bracket 1 | 1; | - | |
| 20 | CQ1460830 | Болт | 4; | - | |
| 21 | 1129065-26E | Pipe clip | 1; | - | |
| 22 | CQ1460620 | Болт | 1; | - | |
| 23 | 1104036-26E | Three way connector | 1; | - | |
| 24 | CQ67616 | Хомут | 4; | - | |
| 25 | 1111010-26E | High pressure pump | 1; | - | |
| 26 | 1111014-X2 | Washer | 3; | - | |
| 27 | Q40308 | Пружинная шайба | 3; | 10 ₽ - 60 ₽ | |
| 28 | CQ34008 | Гайка | 3; | - | |
| 29 | 1129050-26E | Fuel injection line-pump to common rail | 1; | - | |
| 30 | 1129065-26E | Injection line clip assembly | 1; | - | |
| 31 | CQ1500612 | Болт | 1; | - | |
| 32 | 1104034-26E | Fuel return pipe-three way connector to pump | 1; | - | |
| 33 | CQ1461035 | Комбинированный болт | 2; | - | |
| 34 | S1117010-C697 | Fuel filter | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
