Piston & connecting rod
/ FAW CA 4DC2-10E4
1
2
3
4
5
6
7
8
8
8
8
8
8
9
10
11
12
13
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 1004026-55D | Top compression ring | 4; | |
| 2 | 1004027-55D | 2nd compression ring | 4; | |
| 3 | 1004035-26E | Combination oil ring assy | 4; | |
| 4 | 1004016-55D | Piston | 4; | |
| 5 | 1004001-C012 | Oil cooling nozzle | 4; | |
| 6 | 1004045-C012 | Connecting rod | 4; | |
| 7 | 1004062-C012 | Connecting rod bolt | 8; | |
| 8 | 1004059-26E | Connecting rod bearing bush-underside | 4; | |
| 8 | 1004058-26E | Connecting rod bearing bush-upside | 4; | |
| 9 | 1004056-C012 | Connecting rod cap | 4; | |
| 10 | 1004067-X2 | Connecting rod nut | 8; | |
| 11 | 1004069-X3 | Connecting rod small end cap | 4; | |
| 12 | 1004022-X3 | Circlip for hole | 8; | |
| 13 | 1004021-X3 | Piston pin | 4; |
