CAMSHAFT
/ HOWO MC11
1
1.1
2
3
4
5
6
7
8
9
10
11
12
13
14
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 200-04400-6050 | Camshaft assembly | ; | |
| 1.1 | MQ6-22022-0912 | Cylindrical pin | ; | |
| 2 | 200V04410-0177 | Camshaft Bearing | ; | |
| 3 | 200-04501-0191 | Camshaft gear | ; | |
| 4 | 200V04501-0190 | Camshaft pulse plate | ; | |
| 5 | MQ6-03216-8306 | Hex bolt | ; | |
| 6 | 200-04505-5094 | Cylinder head idler gear assembly | ; | |
| 7 | 200V04506-0077 | Small intermediate gear shaft | ; | |
| 8 | MQ6-02191-0410 | Hexagon socket head cap screws | ; | |
| 9 | 200-04505-5093 | Crankcase intermediate gear assembly | ; | |
| 10 | 200V04506-0077 | Small intermediate gear shaft | ; | |
| 11 | MQ6-02191-0410 | Hexagon socket head cap screws | ; | |
| 12 | 200-04505-5133 | Intermediate gear assembly | ; | |
| 13 | 200V04506-0078 | Large intermediate gear shaft | ; | |
| 14 | MQ6-03216-8615 | Hexagon flange bolts | ; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
