FUEL FILTER
/ HOWO MC11
1
1.1.1
1.1.2
1.2
1.3
1.3.1
1.4.1
1.4.2
1.4.3
1.4.4
1.5
1.5.1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 201V12501-7289 | Filter | ; | |
| 1.1 | 201V12503-0061 | Core fuel filter with O-ring | ; | |
| 1.1.1 | 201V12503-0063 | Fine filter cartridge | ; | |
| 1.1.2 | 200V96501-0581 | O-ring | ; | |
| 1.2 | 201V12504-0030 | Filter cover with O-ring | ; | |
| 1.2.1 | 200V96501-0581 | O-ring | ; | |
| 1.3 | 201V12503-0082 | Fuel filter holder with O-ring | ; | |
| 1.3.1 | 200V96501-0621 | O-ring | ; | |
| 1.4 | 201V12150-0002 | Hand pump with bolts | ; | |
| 1.4.1 | 201V12503-0084 | Hand pump filter with O-ring | ; | |
| 1.4.1.1 | 201V12503-0083 | Hand pump filter | ; | |
| 1.4.1.2 | 200V96501-0604 | O-Ring | ; | |
| 1.4.2 | 201V12502-0014 | Hand oil pump cover with O-ring | ; | |
| 1.4.2.1 | 200V96501-0604 | O-Ring | ; | |
| 1.4.3 | 200V96501-0604 | O-Ring | ; | |
| 1.4.4 | 201V90020-0428 | Hexagon shoulder bolts | ; | |
| 1.5 | 201V90310-0268 | Drain cock with O-ring | ; | |
| 1.5.1 | 200V96501-0605 | O-Ring | ; | |
| 2 | 200V12540-5110 | Check valve support | ; | |
| 3 | MQ6-03216-8304 | Hex bolt | ; | |
| 4 | MQ6-03216-8203 | Hexagon head bolt | ; | |
| 5 | MQ6-15013-0409 | Washer | ; | |
| 6 | MQ6-67300-2525 | Retaining clip | ; | |
| 7 | MQ6-03216-8308 | Hex bolt | ; | |
| 8 | 200V97401-0565 | Single pipe clamp | ; | |
| 9 | 200V97430-0001 | Bellows clamp | ; | |
| 10 | 200-12540-6008 | Fuel filter bracket assembly with a pipe clamp | ; | |
| 11 | MQ6-03216-8303 | Hex Bolt | ; | |
| 12 | MQ6-56631-0106 | Sealing ring | ; | |
| 13 | 200V98130-0579 | Connector | ; | |
| 14 | 200V12304-5849 | Fuel filter - fuel pump | ; | |
| 15 | MQ6-56631-0106 | Sealing ring | ; | |
| 16 | MQ6-08049-0031 | Plugs | ; | |
| 17 | 200V98150-0175 | Hollow bolt | ; | |
| 18 | MQ6-56631-0106 | Sealing ring | ; | |
| 19 | 200V98103-0037 | Annular connector | ; | |
| 20 | MQ6-71270-2103 | T-joint | ; | |
| 21 | 200V98130-0671 | Screw-in connector | ; | |
| 22 | MQ6-56631-0106 | Sealing ring | ; | |
| 23 | 200V98103-0037 | Annular connector | ; | |
| 24 | 200V98150-0175 | Hollow bolt | ; | |
| 25 | 200V12305-5298 | Injector return pipe - pressure limiting valve | ; | |
| 26 | 200V12305-5364 | Return line pressure limiting valve - Reducing fittings | ; | |
| 27 | MQ6-15013-0411 | Washer | ; | |
| 28 | MQ6-03216-8303 | Hex Bolt | ; | |
| 29 | MQ6-67300-1036 | Retaining clip | ; | |
| 30 | 200V12305-5300 | Return pipe | ; | |
| 31 | 200V97401-0552 | Dual hose clamp | ; | |
| 32 | 200V12304-5848 | Fuel strainer inlet pipe | ; | |
| 33 | 200V98130-0458 | Screw-fitting | ; | |
| 34 | MQ6-56631-0106 | Sealing ring | ; | |
| 35 | 200V12304-5850 | Fuel pipe pump - Filter | ; | |
| 36 | 200V12304-5851 | Fuel pipe filters - high pressure pump | ; | |
| 37 | 200V98130-0458 | Screw-fitting | ; | |
| 38 | MQ6-56631-0106 | Sealing ring | ; |
