HIGH PRESSURE COMMON RAIL
/ HOWO MC11
1
1.1
1.2
2
3
4
5
6
7
8
9
10
11
12
12.1
12.2
13
14
15
16
17
17.1
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39.1
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 200V10100-6126 | Injector | ; | - | |
| 1.1 | 200V96501-0502 | O-ring | ; | - | |
| 1.2 | 200V98701-0139 | Injector gasket | ; | - | |
| 2 | 200V90720-0214 | Push the stops | ; | - | |
| 3 | 200V10104-0065 | Injector plate | ; | - | |
| 4 | MQ6-15140-2102 | Sphere washer | ; | - | |
| 5 | MQ6-03216-8310 | Hexagon head bolt | ; | - | |
| 6 | 201V10304-0323 | Pressure tubing | ; | - | |
| 7 | MQ6-03216-8310 | Hexagon head bolt | ; | - | |
| 8 | 201V10304-0322 | High-pressure pipeline | ; | - | |
| 9 | 201V10304-0321 | High-pressure pipeline | ; | - | |
| 10 | 201V10304-0320 | High-pressure pipeline | ; | - | |
| 11 | 201V10304-0319 | High-pressure pipeline | ; | - | |
| 12 | 200V10311-6082 | Rail with integrated pressure limiting valve and the throttle valve | ; | - | |
| 12.1 | 200V27421-0229 | Rail pressure sensor | ; | - | |
| 12.2 | 200V10304-0291 | Pressure limiting valve | ; | - | |
| 13 | 201V10304-0318 | High-pressure pipeline | ; | - | |
| 14 | 201V10301-6189 | High-pressure pipeline pumps - Rail | ; | - | |
| 15 | MQ6-03216-8303 | Hex Bolt | ; | - | |
| 16 | 200-10303-0999 | Compression nut | ; | - | |
| 17 | 200-10301-6161 | Injector into the oil takeover | ; | - | |
| 17.1 | 200V96501-0532 | O-ring for high pressure fittings | ; | - | |
| 18 | 200V11103-7792 | High pressure pump CP3.4 + | ; | - | |
| 19 | MQ6-03216-8411 | Hexagon flange bolts | ; | - | |
| 20 | 200V11310-0007 | Shaft sleeve | ; | - | |
| 21 | MQ6-29029-0199 | Hole Spring Collar | ; | - | |
| 22 | 200-38507-5020 | High pressure pump drive housing | ; | - | |
| 23 | 200-11301-0258 | High-pressure oil pump drive gear | ; | - | |
| 24 | MQ6-02191-0409 | Hexagon socket head cap screws | ; | - | |
| 25 | 200V38516-5006 | transmission shaft | ; | - | |
| 26 | MQ6-03216-8516 | Hexagon flange bolts | ; | - | |
| 27 | 201V96501-0573 | Seal | ; | - | |
| 28 | 200V95820-0090 | Pulley | ; | - | |
| 29 | 200V90710-0450 | Shaft washer | ; | - | |
| 30 | MQ6-03216-8506 | Hex bolt | ; | - | |
| 31 | MQ6-03216-8304 | Hex bolt | ; | - | |
| 32 | MQ6-02191-0614 | Cylinder Screw | ; | - | |
| 33 | 200V11302-0053 | The front end of the intermediate gear shaft | ; | - | |
| 34 | 200-11306-5007 | The front end of the intermediate gear | ; | - | |
| 35 | 200V91701-0894 | Positioning bushings | ; | - | |
| 36 | MQ6-22022-3061 | Cylindrical pin | ; | - | |
| 37 | 202V25803-7915 | ECU | ; | - | |
| 38 | MQ6-03216-8206 | Hex bolt | ; | - | |
| 39 | 202V11640-6014 | ECU bracket assembly | ; | - | |
| 39.1 | MQ6-02829-0025 | Hex bolt | ; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
