WATER PUMP
/ HOWO MC11
1
2
3
4
5
6
7
8
9
10
10.1
11
12
13
14
15
16
17
18
19
20
21
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 200V06500-6675 | Pump | ; | - | |
| 2 | 201V06901-0192 | Water pump gasket | ; | - | |
| 3 | 200V06330-5041 | Housing allocation | ; | - | |
| 4 | 201V06903-0061 | Allocation shell gasket | ; | - | |
| 5 | MQ6-56631-0106 | Sealing ring | ; | - | |
| 6 | MQ6-08049-0031 | Plugs | ; | - | |
| 7 | MQ6-03216-8317 | Hex bolt | ; | - | |
| 8 | 200V06303-5846 | Urea heating return pipe | ; | - | |
| 9 | 200V97401-0557 | Single-line bundle Ties | ; | - | |
| 10 | 200V98181-6026 | Screw-through connector | ; | - | |
| 10.1 | 200V96501-0571 | O-ring | ; | - | |
| 11 | MQ6-03216-8305 | Hex bolt | ; | - | |
| 12 | MQ6-03216-8320 | Bolt | ; | - | |
| 13 | MQ6-03215-8302 | Hex bolt | ; | - | |
| 14 | 201V06503-0384 | Pulley | ; | - | |
| 15 | MQ6-03216-8308 | Hex bolt | ; | - | |
| 16 | MQ6-03216-8514 | Hexagon flange bolts | ; | - | |
| 17 | MQ6-03216-8305 | Hex bolt | ; | - | |
| 18 | 200V01905-0092 | Front cover gasket | ; | - | |
| 19 | 200V01501-5037 | Front cover assembly | ; | - | |
| 20 | 200V01510-6008 | Crankshaft front oil seal | ; | - | |
| 21 | MQ6-03216-8308 | Hex bolt | ; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
