Oil pump assembly (double section)
/ SDEC SC11CB220G2B1
1
2
3
4
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
20
21
22
23
24
25
26
26
27
28
29
30
31
31
32
33
34
35
36
37
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 4110001003063 | Rubber hose | 1; | |
| 2 | 4190000536175 | Pipe | 1; | |
| 3 | 4110000186025 | Spacer | 1; | |
| 4 | 4110000186029 | Screw | 3; | |
| 5 | 4110000186030 | Screw | 1; | |
| 6 | 4110000186026 | Screw | 2; | |
| 7 | 4110000186027 | Washer | 4; | |
| 8 | 4110000186024 | Oil pump | 1; | |
| 9 | 4110000186028 | Gear | 1; | |
| 10 | 4110000565008 | Woodruff key | 1; | |
| 11 | 4110000186029 | Screw | 1; | |
| 12 | 4110000186031 | Washer | 1; | |
| 13 | 4110001003095 | Fuel pump | 1; | |
| 14 | 4110001003096 | Pump body | 1; | |
| 15 | 4110001003094 | Input shaft | 1; | |
| 16 | 4110000907099 | Shaft | 1; | |
| 17 | 4110000907100 | Gear | 1; | |
| 18 | 4110000907101 | Spacer plate | 1; | |
| 19 | 4110000907102 | Key | 1; | |
| 20 | 4011000053 | Bolt | 3; | |
| 21 | 4110000907103 | Pressure reducing valve | 1; | |
| 22 | 4110000907104 | Cover | 1; | |
| 23 | 4011001079 | Bolt | 1; | |
| 24 | 4110000907105 | Washer | 1; | |
| 25 | 4110001003099 | Fuel pump | 1; | |
| 26 | 4110000907107 | Bearing bushing | 4; | |
| 27 | 4110001003100 | Fuel pump | 1; | |
| 28 | 4110000907109 | Ball | 1; | |
| 29 | 4110000907110 | Shaft | 1; | |
| 30 | 4110001003098 | Input shaft | 1; | |
| 31 | 4110000907112 | Gear | 2; | |
| 32 | 4110000907113 | Shaft | 1; | |
| 33 | 4110000907114 | Shaft | 1; | |
| 34 | 4110000907115 | Ball | 1; | |
| 35 | 4110000907116 | Pin | 1; | |
| 36 | 4110001002015 | Washer | 3; | |
| 37 | 4110000565009 | Spring washer | 3; | |
| 38 | 4110000907117 | Sleeve | 2; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
