ENGINE APPLICATION PARTS GROUP S00007823+03
/ SDEC SC9D220G2B1
1
2
3
3
3
3
3
4
4
4
4
5
7
10
11
11
13
15
15
16
17
18
19
20
21
24
25
25
26
27
28
29
30
31
31
31
32
33
35
35
36
36
36
36
37
40
40
41
41
41
41
41
44
45
48
49
51
52
53
54
55
56
57
58
59
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | D00-118-22A+A | GASKET, EXHAUST PIPE ELBOW | 1; | |
| 2 | D00-173-01+A | GASKET, EXHAUST PIPE ELBOW | 1; | |
| 3 | B00002000 | BOLT, HEX FLANGE HEAD CAP | 13; | |
| 4 | B00002003 | BOLT, HEX FLANGE HEAD CAP | 7; | |
| 5 | D00-222-01+A | INSERT | 2; | |
| 7 | D00-014-10A+B | BRACKET, MUFFLER | 1; | |
| 10 | S00007313+03 | AIR FILTER BRACKET | 1; | |
| 11 | B00000834 | NUT, HEX FLANGE HEAD CAP | 6; | |
| 13 | S00007328+05 | BRACKET | 1; | |
| 15 | B00001586 | THROAT HOOP | 2; | |
| 16 | D00-270-01+A | HOSE | 1; | |
| 17 | D00-199-19A+B | AIR INLET PIPE, COMPRESSOR | 1; | |
| 18 | D00-145-01+A | JOINT, SERVICE INDICATOR-AIR FILTER | 1; | |
| 19 | B00001856 | COPPER WASHER | 1; | |
| 20 | B00000794 | NUT | 8; | |
| 21 | B00001300 | WASHER, PLAIN | 8; | |
| 24 | D00-105-11+D | JOINT, AIR INTAKE PIPE | 1; | |
| 25 | B00001569 | THROAT HOOP | 4; | |
| 26 | D00-270-03+A | HOSE | 1; | |
| 27 | B00002119 | BOLT, HEX FLANGE HEAD CAP | 1; | |
| 28 | D00-188-03+D | AIR INLET PIPE, AIR COMPRESSOR | 1; | |
| 29 | D00-190-02+A | CLIP | 1; | |
| 30 | D00-105-05+B | ELBOW JOINT | 1; | |
| 31 | B00001998 | BOLT, HEX FLANGE HEAD CAP | 5; | |
| 32 | B00000791 | NUT | 1; | |
| 33 | D00-201-02A+B | CLIP | 1; | |
| 35 | B00002177 | BANJO BOLT | 2; | |
| 36 | B00001545 | RUBBER COATED HARD WASHER | 4; | |
| 37 | D00-106-11+B | OIL INLET PIPE, AIR COMPRESSOR | 1; | |
| 40 | B00002224 | HINGED BOLT | 2; | |
| 41 | B00001547 | RUBBER COATED HARD WASHER | 8; | |
| 44 | S00002817+05 | FUEL RETURN | 1; | |
| 45 | S00002935+01 | FUEL RETURN | 1; | |
| 48 | D00-169-05+A | D00-169-05+A | 1; | |
| 49 | D00-163-14+A | JOINT, WARM WATER | 1; | |
| 51 | D04-150-01+C | CLIP | 1; | |
| 52 | B00002006 | BOLT, HEX FLANGE HEAD CAP | 4; | |
| 53 | D00-101-40A+B | AIR COMPRESSOR BRACKET | 1; | |
| 54 | D00-006-01+B | DIP STICK ASSEMBLY | 1; | |
| 55 | D00-135-01+A | DIPSTICK TAKE OVER | 1; | |
| 56 | D00-230-11+A | POLE | 1; | |
| 57 | D00-277-02+A | POLE | 1; | |
| 58 | D00-228-15+A | BRACKET | 1; | |
| 59 | D00-206-09+A | HOSE, PLAIN | 1; | |
| 60 | D00-142-01+B | AIR COMPRESSOR BANK | 1; | |
| 61 | D00-241-01+A | FUEL RETURN PIPE | 1; | |
| 62 | 761G-26-014B+A | FUEL PIPE, LOW PRESSURE | 1; | |
| 63 | D00-146-01+C | GASKET,OUTTAKE PIPE | 1; | |
| 64 | D02A-163-01+C | PLUG, PIPE | 1; | |
| 65 | B00001698 | BOLT, PIPE | 1; | |
| 66 | D00-190-03+A | CLIP | 1; | |
| 67 | D00-240-09+A | FUEL RETURN | 1; | |
| 68 | D00-154-07+A | HEAT SHIELD PLATE | 1; |
