FRONT GEAR MECHANISM GROUP
/ SDEC SC9DF260Q5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | D16A-003-900 | Tensioner assy | 1; | |
| 2 | B00002028 | Hexagon bolts with flange | 1; | |
| 3 | D16A-106-900 | Belt, fan | 1; | |
| 4 | B00001999 | HEX HEAD BOLT | 1; | |
| 5 | D11-105-30A | BRACKET | 1; | |
| 6 | B00002139 | HEX HEAD BOLT | 1; | |
| 7 | B00001301 | Plain washer | 1; | |
| 8 | B00001020 | ELASTIC PIN | 1; | |
| 9 | B00002069 | Hexagon bolts with flange | 4; | |
| 10 | D16A-111-01A | CLAMP | 1; | |
| 11 | D16A-136-02 | Pulley, end | 1; | |
| 12 | D16A-107-15 | Pulley, fan | 1; | |
| 13 | B00002147 | HEX HEAD BOLT | 4; | |
| 14 | D16A-010-900 | Base assy (pressed), fan bearing | 1; | |
| 15 | D16A-128-36 | Spacer, fan | 1; | |
| 16 | D11-104-01 | Распорная втулка | 1; | |
| 17 | B00001990 | BOLT, HEX FLANGE HEAD CAP | 1; | |
| 18 | D11-103-900 | Alternator bracket | 1; | |
| 19 | B00002054 | Hexagon bolts with flange | 2; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
