ENGINE OIL PUMP GP (TWO SECTION GEAR)
/ SDEC C6121ZG57a
1
2
3
4
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
20
21
22
23
24
25
26
26
27
28
29
30
31
31
32
33
34
35
36
37
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 6N2642 | PUMP GP-ENGINE OIL | 1; | |
| 2 | 4N5353 | ELBOW-SCAVENGE LINE | 1; | |
| 3 | 2P8746 | GASKET | 1; | |
| 4 | 0S1590 | BOLT | 3; | |
| 5 | 0S1619 | BOLT | 1; | |
| 6 | 3B1915 | BOLT | 2; | |
| 7 | 5M2894 | WASHER | 4; | |
| 8 | 4W2448 | ENGINE OIL PUMP AS. | 1; | |
| 9 | 7W0507 | GEAR-OIL PUMP DRIVE | 1; | |
| 10 | 8M5599 | KEY-WOODRUFF-10 | 1; | |
| 11 | 0S1590 | BOLT | 1; | |
| 12 | 1P7346 | WASHER-HARD | 1; | |
| 13 | 4W2321 | BODY ASSEMBLY-SCAVENGE PUMP | 1; | |
| 14 | 4W2322 | BODY AS.-OIL PUMP | 1; | |
| 15 | 2P6245 | DRIVE SHAFT AS. | 1; | |
| 16 | 8S0493 | SHAFT ASSEMBLY-OIL PUMP | 1; | |
| 17 | 6N1036 | GEAR-OIL PUMP | 2; | |
| 18 | 2P1781 | SPACER-OIL PUM | 1; | |
| 19 | 1B8709 | KEY-WOODRUFF-10 | 1; | |
| 20 | GB/T5782-M10x90 | BOLT | 3; | |
| 21 | 4N8385 | PRESSURE RELIEF VALVE AS. | 1; | |
| 22 | 4N3732 | COVER-OIL PUMP BYPASS VALVE | 1; | |
| 23 | GB/T5782-M8x50 | BOLT | 1; | |
| 24 | GB/T97.1-8-200HV | WASHER-HARD | 1; | |
| 25 | 4N4054 | BODY-SCAVENGE PUMP | 1; | |
| 26 | 8S6511 | BEARING-SLEEVE | 4; | |
| 27 | 8N8635 | BODY-OIL PUMP | 1; | |
| 28 | GB/T308-10 | STEEL BALL | 1; | |
| 29 | 2P1170 | SHAFT ASSEMBLY-OIL PUMP IDLER GEAR | 1; | |
| 30 | 2P0691 | DRIVE SHAFT | 1; | |
| 31 | 2P2545 | GEAR-OIL PUMP | 2; | |
| 32 | 8S0490 | SHAFT-OIL PUMP | 1; | |
| 33 | 2P1169 | SHAFT-OIL PUMP IDLER GEAR | 1; | |
| 34 | GB/T308-8 | STEEL BALL | 1; | |
| 35 | 1F1006 | DOWEL | 1; | |
| 36 | GB/T97.1-10-200HV | WASHER | 3; | |
| 37 | GB/T93-10 | WASHER | 3; | |
| 38 | 4N8384 | SPRING-CONED DISC | 5; | |
| 39 | 8N8118 | PEDESTAL | 1; | |
| 40 | 2P7717 | RETAINER | 1; | |
| 41 | 15AL001 | SHEATH | 2; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
