Back cover assembly
/ Shaanxi Fast BJ-G25930-12JSDX240TA+FHB400+QH50
1
2
3
4
5
6
7
8
10
11
12
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
35
36
37
38
39
40
41
42
43
44
45
46
47
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 12JSD2X240TA-1707010-56 | 12JSD2X240TA-1707010-56 | Rear cover shell assembly | 1; | |
| 32216 | 32216 | Tapered Roller Bearings | 1; | |
| RTD-11609A-1707054-1 | RTD-11609A-1707054-1 | Locating ring | 1; | |
| 12JSD200T-1707047-6 | 12JSD200T-1707047-6 | Auxiliary box extended intermediate shaft welding assembly | 1; | |
| GB3452_1-132X3_55 | GB3452_1-132X3_55 | O-ring | 1; | |
| QH70-4211401-1 | QH70-4211401-1 | Цилиндр среднего положения | 1; | |
| 1 | RTD-11609A-1707067 | Auxiliary box shift fork | 1; | |
| 2 | 12JSD200T-1707060-1 | Auxiliary box cylinder small assembly | 1; | |
| 3 | 14347 | Прокладка | 1; | |
| 4 | 12JSD200T-1707065-1 | Auxiliary box cylinder block assembly | 1; | |
| 5 | 14349 | Прокладка корпуса цилиндра | 1; | |
| 6 | 12JSD200T-1707066-1 | Auxiliary box cylinder piston assembly | 1; | |
| 7 | 12JSD200T-1707050-1 | Вал КОМ | 1; | |
| 8 | 12JSD200T-1707016-1 | Back cover | 1; | |
| 10 | 192311E | Подшипник | 2; | |
| 11 | Q433120 | Стопорное кольцо | 2; | |
| 12 | JS180-1707051 | Стопорное кольцо | 2; | |
| 15 | FQZH0210G185TF6 | Hex head bolt and spring washer assembly | 1; | |
| 16 | Q1421055 | Hex head bolt and spring washer assembly | 3; | |
| 17 | Q171B0825 | Hexagon head bolts with holes - fine thread | 12; | |
| 18 | Q171B1250 | Болт с 6-ти гранной головкой | 2; | |
| 19 | 12JSD200T-1707072-3 | Bearing seat | 1; | |
| 20 | 12JSD200T-1707068-2 | Adjusting washer | 2; | |
| 21 | JS220-1707111 | Втулка шестерни | 1; | |
| 22 | Q12014100 | Studs | 2; | |
| 23 | Q40310 | Пружинная шайба | 1; | |
| 24 | FQZH0210G165TF6 | Hex head bolt and spring washer assembly | 4; | |
| 25 | Q1421032M | Болт с и пружинная шайба | 4; | |
| 26 | 12JSDX240T-1701157-3 | Odometer rotor | 5; | |
| 27 | C03054-16 | Electronic odometer sensor assembly | 1; | |
| 28 | 12JSD200T-1707019-4 | Spindle rear bearing cover | 1; | |
| 29 | 19109-2 | Сальник | 1; | |
| 30 | Q1421085 | Hex head bolt and spring washer assembly | 3; | |
| 31 | Q40308 | Пружинная шайба | 12; | |
| 32 | FHB400-SQ1 | Parallel hydraulic retarder | 1; | |
| 33 | F96119 | Крышка пылезащитная | 1; | |
| 35 | Q12014140 | Studs | 3; | |
| 36 | Q32014 | Hexagonal flange nut | 5; | |
| 37 | Q1421040 | Болт с пружиной шайбой | 11; | |
| 38 | 12JSD200T-1707021-1 | Auxiliary box intermediate shaft end face gland | 2; | |
| 39 | 12JSD200T-1707022-4 | Retarder passive gear | 1; | |
| 40 | 12JSD200T-1707015-1 | Back cover body | 1; | |
| 41 | Q5211645 | Cylindrical pin | 2; | |
| 42 | JM714249-210-Q | Tapered Roller Bearings | 1; | |
| 43 | 12JSDX240T-1707108 | Прижимная пластина шестерни | 1; | |
| 44 | 12JSD200T-1707105-14 | Auxiliary box spindle | 1; | |
| 45 | 12JSDX240T-1707107 | Шестерня вала КОМ | 1; | |
| 46 | 12JSDX240T-1707106-2 | Auxiliary box main shaft reduction gear | 1; | |
| 47 | 11847140-1 | Synchronizer assembly | 1; |
