Air Intake Manifold Assembly
/ Weichai R6160
1
2
2
3
3
3
3
3
3
3
3
3
3
4
5
6-3
6-4
6-5
7
7
8
8
B1
B1
B2
B2
B2
B3
В4
В5
В6
B7
В8
В8
В9
В10
B11
B12
B13
| Поз. | Артикул | Название детали | R6160 ZC1 | R6160 ZC2 | R6160 ZC3 | R6160 ZC4 | R6160 A-1 | R6160 A-2 | R6160 A-3 | R6160 A-4 | R6160 A-5 | R6160 A-6 | R6160 Z-1 | Цена | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 160A.18.09 | End cover | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 2 | 160A.18.08 | Washer | 2 | 2 | 2 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | - | |
| 3 | 6160А-11.18А.30 | Mr intake manifold sub-assy | 1 | 1 | 1 | 1 | - | |||||||||
| 3 | 6160ZC5.18.80 | Air inlake manifold sub-assy | 1 | 1 | 1 | 1 | - | |||||||||
| 3 | 616OZC1.18.80A | Air inlake manifold sub-assy | 1 | 1 | - | |||||||||||
| 3 | 6160A-18.18.30 | Air inlake manifold sub-assy | 1 | - | ||||||||||||
| 3 | 616018160300 | Air inlake manifold sub-assy | 1 | - | ||||||||||||
| 4 | 616018110001 | Pipe | 1 | 1 | - | |||||||||||
| 4 | 616018120001 | Pipe | 1 | 1 | - | |||||||||||
| 5 | 160А.18.05 | Gasket | 6 | 6 | 6 | 6 | 6 | 6 | - | |||||||
| 5 | 160Z.8.05 | Gaskel | 6 | 6 | 6 | 6 | 6 | 6 | - | |||||||
| 6 | 616018010100 | Air cleaner sub-assy | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 6-1 | 160А.18.50.01 | Outer cover | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 6-2 | 160Z.18.50.09 | Screen | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 160Z.18.50.11 | 160Z.18.50.11 | Screen | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 160Z.18.50.12 | 160Z.18.50.12 | Screen | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 160Z.18.50.13 | 160Z.18.50.13 | Outer ring | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 160Z.18.50.14 | 160Z.18.50.14 | Inner ring | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 6-3 | 160A.18.20.04 | Plug | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 6-3 | 160Z.18.50.07 | Screen | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 160Z.18.50.08 | 160Z.18.50.08 | Enter, cover | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 5GB/97.1-140HY-Zn-D | 5GB/97.1-140HY-Zn-D | Washer | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 5x8 GB/T867 | 5x8 GB/T867 | Rivet | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | - | |
| 6-4 | 160Z.18.50.04 | Pipe clamp | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 6-5 | 160Z.18.50.06 | Seal gasket | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| 7 | 160A.18.06 | Pipe clamp | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| 8 | 160А.18.11А | Rubber pipe | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| B1 | М10х25 GB/T5783 | Hexagon bolt | 34 | 28 | 28 | 28 | 28 | 28 | 28 | 28 | 28 | 36 | 34 | 34 | - | |
| B2 | 10GB/T93 | Spring washer | 36 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 36 | 36 | 36 | - | |
| B3 | М10х25 GB/T898-8-8-Н-Y | Stud | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| В4 | M10 GB/T6170-H-Y | Hexagon nut | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| В5 | 90003960005 | Hexagon plug | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| В6 | 160A.13.36 | Copper-asbestos washer | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| B7 | 90012040002 | Wing nut | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| В8 | 8GB/T93 | Sping washer | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| В9 | 8GB/T97-1-140HV-Zn-D | Washer | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| В10 | М8x35GB/T5783 | Hexagon holt | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| B11 | 90012210023 | Hexagon nut | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | |
| B12 | M6x30 | Screw | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - | |
| B13 | М6 GB/T6170-H-Y | Hexagon nut | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
