Cylinder Head Assembly (1)
/ Weichai WP2.1D18E2
1
2
3
4
5
6
7
8
9
9
9
9
9
9
9
9
10
11
12
12
12
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | T/Y80.02-4 | Cap nut | 5; | |
| 2 | T/Y80.02-3 | Rubber washer | 5; | |
| 3 | T/Y80.02-2 | Clamping plate | 5; | |
| 4 | YT4102Q1-01023 | Oil filler plug | 1; | |
| 5 | YZ485QB-01140A | Cylinder head cover | 1; | |
| 6 | YZ485ZLQ-01141 | Cylinder head cover gasket | 1; | |
| 7 | YZ480.01.2.2-1 | Rocker arm shaft | 1; | |
| 8 | 495-01111 | Rocker arm shaft plug | 2; | |
| 9 | 2BTDQ-D8 | Washer | 29; | |
| 10 | 2BLS-M8X45/8.8 | Bolt | 5; | |
| 11 | 2BLS-M8X60/8.8 | Bolt | 5; | |
| 12 | 2BLM-M8 | Nut | 13; | |
| 13 | T/Y80.01.2-5 | Rocker arm shaft clamping bolt | 2; | |
| 14 | YZ485QB-01111 | Valve clearance adjusting screw | 8; | |
| 15 | 2BLM-M8X1 | Nut | 8; | |
| 16 | 2BLZ-AM8X25 | Stud | 3; | |
| 17 | YZ485QB-01116 | Rocker arm shaft bracket | 2; | |
| 18 | T/Y80.01.2-4 | Rocker arm spacer | 8; | |
| 19 | T/Y80.01.2.1-2 | Rocker arm bushing | 8; | |
| 20 | T/Y80.01.2.1-1 | Rocker arm | 8; | |
| 21 | YZ485QB-01117 | Rocker arm shaft bracket | 3; | |
| 22 | T/Y80.01.2-3 | Rocker arm shaft spring | 4; | |
| 23 | T/Y80.01-12A | Rear lifting eye | 1; | |
| 24 | 2BLS-M8X16/8.8 | Bolt | 4; | |
| 25 | YZ485D-12105 | Fuel filter bracket | 1; | |
| 26 | 2BLS-M8X20/8.8 | Bolt | 2; | |
| 27 | YZ485-10 | Intake manifold gasket | 4; | |
| 28 | 2BLZ-AM8X16-1 | Stud | 8; | |
| 29 | T/Y80.01-11A | Front lifting eye | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
