Cylinder block subassembly
/ Weichai WP6G175E201
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | 4110001525005 | Cylinder block | 6; | |
| 2 | 4110000054002 | O-ring | 12; | |
| 3 | 4110000054003 | O-ring | 12; | |
| 4 | 4110002122042 | Plug | 7; | |
| 5 | 4110002122039 | Plug | 1; | |
| 6 | 4110000054295 | Bushing | 1; | |
| 7 | 4110000054272 | Plug | 7; | |
| 8 | 4110000054270 | Plug | 2; | |
| 9 | 4110000846134 | Bushing | 5; | |
| 10 | 4110000846135 | Bushing | 1; | |
| 11 | 4110002122028 | Bushing | 1; | |
| 12 | 4110000924141 | Stud | 4; | |
| 13 | 4110001948004 | Screw | 12; | |
| 14 | 4110001031050 | Cover | 1; | |
| 15 | 4110001948005 | Screw | 2; | |
| 16 | 4110001948003 | Cover | 6; | |
| 17 | 4110000054029 | Spring pin | 1; | |
| 18 | 4110000846136 | Plug | 1; | |
| 19 | 4110000054068 | Bracket | 1; | |
| 20 | 4110000054023 | Washer | 1; | |
| 21 | 4110000054198 | Screw | 1; | |
| 22 | 4110000054001 | O-ring | 1; | |
| 23 | 4110000054078 | Inlet manifold | 1; | |
| 24 | 4110000846147 | Pin | 1; | |
| 25 | 4110000054277 | Stud | 1; | |
| 26 | 4110001948001 | Crankcase | 1; | |
| 27 | 4110000054271 | Plug | 3; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
