Fuel pump assembly
/ XINCHAI 498BPG
1
2
3
4
5
6
7
7
7
8
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
24
25
26
27
28
29
30
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | B1-2 | Protection cap | 4; | - | |
| 2 | B4QA003.2-01 | Delivery valve holder | 4; | - | |
| 3 | B4QA003.2-02 | Spindle | 4; | - | |
| 4 | B4Q001.2-03 | Washer for delivery valve | 1; | - | |
| 5 | B4Q001.2-04 | Delivery valve spring | 4; | - | |
| 6 | F21.0 | Delivery valve | 4; | - | |
| 7 | GB6170-1986 | Screw M6 | 12; | - | |
| 8 | GB93-1987 | Washer 6 | 15; | - | |
| 9 | B4Q001-04 | Washer | 8; | - | |
| 10 | B4QA003.2-03 | Washer for delivery valve | 4; | - | |
| 11 | B4Q001-02 | Adjustble washer | 1; | - | |
| 12 | X119A.0 | P/Element | 4; | - | |
| 13 | B4Q001.2-08 | Seal-П | 4; | - | |
| 14 | B4Q001.2-10 | Seal-IV | 4; | - | |
| 15 | B4QA003-01 | Adjustble gear | 4; | - | |
| 16 | B4Q001.1-04 | Binder bolt | 8; | - | |
| 17 | B4Q001-20 | Banjo bolt | 1; | - | |
| 18 | B4Q001-25 | Washer | 1; | - | |
| 19 | B4Q001-16 | Throtde lever case | 1; | - | |
| 20 | B4Q001-17 | Washer | 1; | - | |
| 21 | B4QA003.1-02 | Washer | 1; | - | |
| 22 | B4QA003.1-01 | Fuel inlet connection | 1; | - | |
| 23 | B4Q001-18 | Washer | 4; | - | |
| 24 | B4Q001-19 | Protection washer | 2; | - | |
| 25 | B4Q001.6-04 | Fule back connection screw | 1; | - | |
| 26 | GB308-1977 | Steel ball 6G40b | 1; | - | |
| 27 | B4Q001.6-03 | Spring | 1; | - | |
| 28 | B4Q001.6-02 | Washer | 1; | - | |
| 29 | B4Q001.6-01 | Screw | 1; | - | |
| 30 | B4Q001.1-02 | Washer | 2; | - | |
| 31 | B4Q001.1-03 | Fuel pipe plug | 1; | - | |
| 32 | B4Q001-23 | Fixing pin | 1; | - | |
| 33 | GB297-1994 | Roller bearing 30203 | 1; | - | |
| 34 | B4Q001.4-01 | Camshaft adjustble washer | 1; | - | |
| 35 | B4QA001.4-02 | Camshaft | 1; | - | |
| 36 | GB1099-1979 | Shaft 4x6.5x16 | 1; | - | |
| 37 | B4QA001.4-01 | Camplate | 1; | - | |
| 38 | GB297-1994 | Roller bearing 30203 | 1; | - | |
| 39 | B4QA001-04 | Bearing adjustble washer | 1; | - | |
| 40 | B4QA001.5-01 | Seal | 1; | - | |
| 41 | B4QA001.5-02 | Bearing cap | 1; | - | |
| 42 | GB819-85 | Screw M6x14 | 4; | - | |
| 43 | B4QA001-05 | Protection case | 1; | - | |
| 44 | GB93-1987 | Washer 6 | 1; | - | |
| 45 | GB6171-1986 | Screw M14x1.5 | 1; | - | |
| 46 | B4Q001.1-01 | Fuel inlet and back connection | 1; | - | |
| 47 | В2-2 | Fuel inlet adaptor | 1; | - | |
| 48 | X4BQA85Y022H | Label | 1; | - | |
| 49 | GB827-1986 | Label rivet 2x5 | 2; | - | |
| 50 | B4Q001-01 | Feed pump seal | 1; | - | |
| 51 | B4Q001.1-06 | Binder bolt | 3; | - | |
| 52 | B4Q023.1-02 | Connection | 1; | - | |
| 53 | B4Q023-02 | Washer | 2; | - | |
| 54 | B4Q023-04 | Protection washer | 1; | - | |
| 55 | B4Q023-03 | Fuel inlet and back screw | 1; | - | |
| 56 | B4Q001-07 | Pump element spring | 4; | - | |
| 57 | B4QA001-02 | Pump element spring | 4; | - | |
| 58 | B4Q001-09 | Pump element spring | 4; | - | |
| 59 | B4QA001.3-01 | Tappet assy | 4; | - | |
| 60 | GB29.1-1988 | Screw M6x14 | 4; | - | |
| 61 | B4Q001-13 | Plate | 1; | - | |
| 62 | B4Q001-12 | Plate seal | 1; | - | |
| 63 | B4QA003.1-03 | Pump housing | 1; | - | |
| 64 | GB119-1986 | Pin D5x12 | 2; | - | |
| 65 | B4Q001-11 | Washer | 5; | - | |
| 66 | B4Q001-10 | Fixing screw | 5; | - | |
| 67 | B4Q001.1-07 | Throttle case | 1; | - | |
| 68 | B4Q001-21 | Spring | 1; | - | |
| 69 | B4Q001-22 | Ring | 1; | - | |
| 70 | GB894.1-1986 | Ring 9 | 1; | - | |
| 71 | B4Q001-06 | Throtde lever | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
