J3600-1010000/12 Oil Collector Assembly
/ Yuchai YC6J210N-52

Тип техники Не выбрано Грузовые Двигатели

Марка Не выбрано Caterpillar Cummins DCEC Deutz DongFeng Doosan FAW HOWO IVECO Komatsu SDEC Shaanxi Shaanxi Fast SITRAK Weichai XINCHAI Yuchai ZF КамАЗ ЯЗДА

Модель Не выбрано YC4108C (D7400) (2010) YC4108ZG (D7802) (2010) YC4112ZQ (ZLQ) (2002) YC4A100-T301 (A515TB) (2021) YC4A115Z-T20 (2013) YC4A125Z-T21 (2016) YC4B105Z-T20 (2016) YC4B90-T10 (2016) YC4D (2005) YC4D120-20 (2008) YC4D120-20 (D1007) (2010) YC4D120-30 (D22J1) (2010) YC4D130-20 (D08FL) (2010) YC4D130-30 (D2102) (2010) YC4D140N-50 (2018) YC4D80-T10 (2009) YC4D80-T20 (2013) YC4D85Z-T20 (2014) YC4E135-21 (E02D1) (2010) YC4E140-20 (E12N2) (2010) YC4E140-30 (E24FB) (2010) YC4E140-33 YC4E150-20 (E05D1) (2010) YC4E160-20 (E04F1) (2010) YC4E180-30 (E2100) (2010) YC4F100-20 (F31D8) (2010) YC4F115-20 (F30D8) (2010) YC4F115-30 (F50D1) (2010) YC4F90-23 (F60LA) (2010) YC4F90-30 (2008) YC4F90-30 (F51D1) (2010) YC4FA130-30 (FC7LA) (2010) YC4G180-20 (2014) YC4G180-20 (G0803) (2008) YC4G180-20 (G0803) (2010) YC4G180-30 (G2H0B) (2010) YC4G180N-30 (G2C0H-T1) (2010) YC4G180N-40 (2014) YC4G190N-50 (2014) YC4G200-30 (G2GQA) (2010) YC4G220-20 (G20JA) (2010) YC4ND27-90-30 (FD2D1) (2010) YC6108G (2008) YC6A240-20 (A3515) (2010) YC6A240-30 (A68SA) (2010) YC6A260-20 (A44AB) (2010) YC6A260-30 (A64YA) (2010) YC6B125-T10 (B7626) (2010) YC6B125-T11 (2016) YC6B125-T20 (2010) YC6B125-T21 (2016) YC6G220P-30 (G3FQA) (2010) YC6G230N-30 (G69MA) (2010) YC6G240-20 (G52MA) (2010) YC6G240-30 (2008) YC6G240-30 (G5BSB-T2) (2010) YC6G260N-20 (G64HA) (2010) YC6G260N-30 (G66YA-T12) (2010) YC6G260N-50 (2015) YC6G270-20 (G46MB) (2010) YC6G270-30 (G65QA) (2010) YC6G300-20 (G4704) (2010) YC6J125Z-T20 (2010) YC6J125Z-T21 (2015) YC6J125Z-T22 (2014) YC6J180-21 (J49D1) (2010) YC6J190-20 (J41D7) (2010) YC6J190-T301 (2021) YC6J190N-40 (J4B0C-C) (2013) YC6J210-20 (J42SA) (2010) YC6J210N-20 (J530C) (2010) YC6J210N-52 (2018) YC6J220-50 (2017) YC6J225N-52 (2014) YC6J230-20 (J4090) (2010) YC6J245-30 (J61LA) (2010) YC6J245-42 (J010N-T1) (2010) YC6J245-50 (2017) YC6K (2019) YC6K440N-50 (2013) YC6L250L-D30 (L7001) (2010) YC6L260-30 (2008) YC6L280-30 (L38MA) (2010) YC6L280N-52 (2014) YC6L310-30 (L360A) (2010) YC6L310-50 (2017) YC6L330-20 (L33YA) (2010) YC6L330-30 (L47SA) (2010) YC6L350-20 (L30JA) (2010) YC6M220G (M3020) (2010) YC6M280-20 (M36T1) (2010) YC6M290N-30 (M2CD1) (2010) YC6M290N-30 (M2CE1) (2010) YC6M320N-30 (M2BD1) (2010) YC6M340-20 (2009) YC6M340N-30 (M2AE1) (2010) YC6M360-30 (M6298) (2010) YC6M390-30 (M6000) (2010) YC6MK300N-50 (MN70A-C) (2015) YC6MK320N-50 (2013) YC6MK340N-50 (2013) YC6MK340N-50 (MN301-C) (2014) YC6MK375N-40 (2014) YCD4F YCD4T32

Схема > Не выбрано J3FSA-1002000/02 Cylinder Block Assembly J3FSA-1002200/04 Gear Housing Part J3EMA-1003000/03 Cylinder Head and Cylinder Head Cover Assembly J3D00-1004000/04 Piston Connecting Rod Assembly J3FSA-1005000/03 Crankshaft Vibration Damper Assembly J3D00-1006000/02 Camshaft Assembly J3C00-1007000/01 Valve Train System Assembly J4R00-1008100/07 and J3C00-1008500/03 Intake Manifold Part J3601-1008200/01 Exhaust Pipe Parts J3F0A-1009000/03 Oil Sump Assembly J3C9A-1028000/01 Oil Dipstick Part J3600-1010000/12 Oil Collector Assembly B78C0-1011000/01 Oil Pump Subassembly B3000-1012000/06 Oil Strainer Assembly J53AA-1013000/17 Oil Radiator Assembly J3C00-1014000/04 Crankcase Ventilation Device Assembly J3FSA-1107000/02 Low-pressure gas filter Assembly J3ESD-1113000/02 Gas Supply Device Assembly J3CSA-1118000/01 Turbocharger Assembly CT-GC06RSBN5-0036/01 Catalytic Converter Assembly J540A-1303000/08 Water Pipe and Hose of Radiator Assembly 631-1305000/08 Water Drain Cock Assembly J540D-1306000/08 Thermostat Assembly J4TLA-1307000/06 Water Pump Assembly J54SA-1600000/01 Power Output Assembly J4VSA-3407000/01 Steering Pump Assembly J3FSC-3509000/01 Pneumatic Air Compressor Assembly J6298-3708000/01 Starter Assembly J4TLA-3701000/04 Generator Assembly J3ESB-3823000/03 Control System Assembly J3C00-3705000/02 Ignition System Assembly J3601-3800000/03 Instrument and Sensor Assembly G4RYA-3904000/01 Data Plate

1

2

3

4

5

6

7

8

9

10

Поз.	Артикул		Название детали	Кол-во	Цена
1	B7503-1010150		Gasket union part	1;	-
2	Q40108		Шайба 8	4;	-
3	Q40308		Шайба 8	6;	30 ₽ - 60 ₽
Шайба пружинная Q40308 / КИТАЙ / Q40308 30 ₽ Болт шестигранный + шайба пружинная КПП Fastgear / Q150B0812+Q40308 40 ₽ Шайба пружинная / Q40308 60 ₽
4	Q/YC1820820TF2		Бoлт M8x20	2;	-
5	430-1010010		Сварной кронштейн зажима трубы I	1;	-
6	Q/YC1820816TF2		Bolt	2;	-
7	6105QJ-1010020A		Сварной зажим трубы II	1;	-
8	6105QA-1010130B		Сетка маслоприёмника в сборе	1;	-
9	J3600-1010030A		Сварной элемент всасывающей трубки	1;	-
10	Q150B0860TF2		Болт М8х60	2;	-

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
