K7501-1312000 Heat Exchanger Assembly
/ Yuchai YC6K
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | K7500-1312204 | Rubber tube | 1; | |
| 2 | Q1841230TF2 | Болт М12х30 | 2; | |
| 3 | K7500-1312005-FF | Outlet pipe | 1; | |
| 4 | Q/YC147.1-81 | Strap 81 | 2; | |
| 5 | K7500-1312006 | The water outlet pipe gasket | 1; | |
| 6 | Q1841025TF2 | Болт М10х25 | 6; | |
| 7 | K7500-1312051 | Flanged joint | 1; | |
| 8 | Q1841235TF2 | Болт M12x35 | 8; | |
| 9 | K7500-1312140 | Zinc bar component | 1; | |
| 10 | Q618B03 | Пробка NPT3/8 | 2; | |
| 11 | K7500-1312103 | Influent cover | 1; | |
| 12 | YC208-E18000F | O-ring 7x180 | 3; | |
| 13 | K7500-1312105 | Sea ring | 2; | |
| 14 | K7500-1312101SF2 | Cooler box | 1; | |
| 15 | K7500-1312106 | Sealing strip | 1; | |
| 16 | KN100-1119203 | Water pipes | 1; | |
| 17 | Q/YC149-14 | Комбинированная уплотнительная шайба 14 | 1; | |
| 18 | K6000-1303017A | Разъем сапуна | 1; | |
| 19 | Q1840612 | Болт | 4; | |
| 20 | K7500-1312150 | The tank cover components | 1; | |
| 21 | K7500-1312012 | Gasket | 1; | |
| 22 | K7500-1312102KS1 | Cooler core | 1; | |
| 23 | K7500-1312104 | The water end cover | 1; | |
| 24 | KN100-1119241 | Return pipe | 1; | |
| 25 | KN100-1312070 | Water pipe clamp assembly | 1; | |
| 26 | YC7-35 | Заглушка | 2; | |
| 27 | Q/YC147.1-66 | Loop hoop | 2; | |
| 28 | K7501-1312015A | Heat exchanger stents | 1; | |
| 29 | Q1841285TF2 | Болт | 1; | |
| 30 | Q18412100TF2 | Болт M12x100 | 4; | |
| 31 | KN3A0-1312004 | Water inlet connection | 1; | |
| 32 | Q1841260TF6 | Bolt M12X60 | 4; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
