MY6MA-1113000/06 Gas Supply Device Assembly
/ Yuchai YC6MK320N-50
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | Q150B0840 | Болт M8x40 | 4; | - | |
| 2 | Q40108 | Шайба 8 | 4; | - | |
| 3 | Q40308 | Шайба 8 | 4; | 30 ₽ - 60 ₽ | |
| 4 | MKC00-1113555 | Mixer gasket | 1; | - | |
| 5 | K1A00-1113540 | Газовый смеситель | 1; | - | |
| 6 | MKC00-1113554 | Mixer gasket | 1; | - | |
| 7 | MYB00-1113640 | Electronic throttle valve | 1; | - | |
| 8 | Q218B0650TF2 | Винт | 4; | - | |
| 9 | Q67689 | Hoop loop | 2; | - | |
| 10 | K1A00-1113642 | Труба дросселя | 1; | - | |
| 11 | MY200-1113601 | Throttle valve intake connecting pipe | 1; | - | |
| 12 | Q1840816 | Болт M8x16 | 2; | 150 ₽ | |
| 13 | MYB00-1113950C | Bracket | 1; | - | |
| 14 | Q1201085 | Stud | 2; | - | |
| 15 | Q40110 | Шайба 10 | 2; | - | |
| 16 | Q340B10 | Гайка М10 | 2; | 100 ₽ | |
| 17 | Q40310 | Шайба 10 | 2; | - | |
| 18 | K1A00-1113301 | Запорный клапан низкого давления топлива | 1; | - | |
| 19 | K1A00-1113C61 | Air outlet joint | 2; | - | |
| 20 | MYB00-1113912 | Трубка соединительная | 1; | - | |
| 21 | Q1840845 | Болт M8x45 | 4; | - | |
| 22 | MKB00-1113911 | Cushion block | 4; | - | |
| 23 | MKB00-1113907 | Anti-vibration pad | 8; | - | |
| 24 | MKB00-1113906 | Spacer sleeve | 4; | - | |
| 25 | Q218B0660TF2 | Винт M6X60 | 4; | - | |
| 26 | MYF00-1113901 | Gas intake common rail pipe | 1; | - | |
| 27 | N100-1113912 | Air intake joint | 1; | - | |
| 28 | YC208-B01800F | Уплотнительное кольцо 2,65x18 | 4; | - | |
| 29 | MKB00-1113903 | Support sleeve | 4; | - | |
| 30 | MYB00-1113905 | Plug | 1; | - | |
| 31 | MYF00-1113902 | Gas outlet common rail pipe | 1; | - | |
| 32 | Q1840855 | Болт M8x55 | 4; | - | |
| 33 | K1A00-1113940SF1 | Metering valve | 5; | - | |
| 34 | TN100-1113553 | Mixer joint | 1; | - | |
| 35 | K1A00-1113909 | Thrust gum cover | 5; | - | |
| 36 | K1A00-1113905 | Plug | 1; | - | |
| 37 | Q1841225 | Болт | 2; | 270 ₽ | |
| 38 | MKB00-38231J0 | Nature gas temperature & pressure sensor | 1; | - | |
| 39 | Q1841220 | Гайка M12x20 | 1; | - | |
| 40 | MYB00-1113650A | Bracket | 1; | - | |
| 41 | Q67632 | Петля обруча 32 | 2; | - | |
| 42 | MYB00-1113551B | Mixer connecting pipe | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
