CONNECTING PARTS
/ ZF КПП ZF 16S151 (вар.)
/9.gif)
10
30
50
70
90
90
90
150
150
150
160
170
250
270
270
270
270
270
272
272
300
320
320
320
320
320
322
322
370
370
370
370
370
370
370
370
370
370
370
370
370
370
370
370
370
370
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 10 | 6038.202.043 | Cut-off valve | 1; | 2 060 ₽ - 3 780 ₽ | |
| 30 | 0501.209.188 | Шариковый ролик | 1; | - | |
| 50 | 0501.209.188 | Шариковый ролик | 1; | - | |
| 70 | 0634.313.505 | Уплотнительное кольцо | 1; | - | |
| 90 | 0636.010.575 | Болт 6-гранный | 4; | - | |
| 90 | 0630.001.075 | Шайба | 4; | - | |
| 150 | 1315.307.019 | Screw | 1; | - | |
| 150 | 0730.009.515 | Sealing ring | 1; | - | |
| 160 | 1315.307.173 | Bolt | 1; | - | |
| 170 | 0732.041.500 | COMPRSPRING | 1; | 400 ₽ | |
| 250 | 0731.208.230 | Pin | 1; | 720 ₽ | |
| 270 | 0501.216.474 | SWITCH | 1; | - | |
| 270 | 0634.801.062 | SEALING RING | 1; | 80 ₽ | |
| 270 | 0700.300.427 | PROTECTING CAP | 1; | - | |
| 272 | 6029.199.111 | PLUG KIT | 1; | - | |
| 272.110 | 6029.201.618 | PLUG | 1; | - | |
| 300 | 0731.208.230 | Pin | 1; | 720 ₽ | |
| 320 | 0501.210.058 | SWITCH | 1; | 5 760 ₽ | |
| 320 | 0634.801.062 | SEALING RING | 1; | 80 ₽ | |
| 320 | 0700.300.427 | PROTECTING CAP | 1; | - | |
| 322 | 6029.199.111 | PLUG KIT | 1; | - | |
| 322.110 | 6029.201.618 | PLUG | 1; | - | |
| 370 | 1315.207.015 | Detent plunger | 1; | - | |
| 370 | 0730.007.835 | Washer | 1; | - | |
| 370 | 0730.007.834 | Washer | 1; | - | |
| 370 | 0730.007.833 | Washer | 1; | - | |
| 370 | 0730.007.832 | Washer | 1; | - | |
| 370 | 0730.007.831 | Washer | 1; | - | |
| 370 | 0730.007.621 | Washer | 1; | - | |
| 370 | 0730.007.620 | Washer | 1; | - | |
| 370 | 0730.007.619 | Washer | 1; | - | |
| 370 | 0730.007.618 | Washer | 1; | - | |
| 370 | 0730.007.617 | Washer | 1; | - | |
| 370 | 0730.007.616 | Washer | 1; | - | |
| 370 | 0730.007.615 | Washer | 1; | - | |
| 370 | 0730.007.614 | Washer | 1; | - | |
| 370 | 0730.007.613 | Washer | 1; | - | |
| 370 | 0730.007.612 | Washer | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
