Вал вторичный
/ ZF КПП ZF 6S1000TO
/4.gif)
10
20
30
50
50.110
50.120
50.120
50.120
50.130
50.140
50.150
50.160
50.170
50.180
50.190
50.200
50.210
50.220
50.220
50.220
50.230
60
70
80
90
90
90
100
110
120
130
140
150
190
200
200
200
250
260
270
280
280.10
280.20
280.30
280.30
280.40
280.60
290
300
310
320
330
330
330
340
350
360
370
380
380.10
380.20
380.30
380.30
380.40
380.60
390
400
410
430
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 10 | 1346.304.107 | MAIN SHAFT | 1; | |
| 20 | 0750.115.567 | NEEDLE CAGE | 1; | |
| 30 | 1346.304.054 | HELICAL GEAR | 1; | |
| 50 | 1346.204.001 | SYNCHRONIZER | 1; | |
| 50.110 | 1346.304.092 | CLUTCH DISC | 1; | |
| 50.120 | 1346.304.039 | INNNER RING | 1; | |
| 50.120 | 1346.304.032 | INNNER RING | 1; | |
| 50.130 | 1346.304.038 | INTERMRING | 1; | |
| 50.140 | 1346.304.033 | OUTER RING | 1; | |
| 50.150 | 1346.304.091 | SYNCHROBODY | 1; | |
| 50.160 | 1312.304.159 | COUPLING ELEMENT | 3; | |
| 50.170 | 6002.305.994 | SLIDING SLEEVE | 1; | |
| 50.180 | 0732.040.409 | COMPRSPRING | 3; | |
| 50.190 | 1297.304.436 | PRESSURE PIECE | 3; | |
| 50.200 | 1346.304.033 | OUTER RING | 1; | |
| 50.210 | 1346.304.038 | INTERMRING | 1; | |
| 50.220 | 1346.304.039 | INNNER RING | 1; | |
| 50.220 | 1346.304.032 | INNNER RING | 1; | |
| 50.230 | 1346.304.092 | CLUTCH DISC | 1; | |
| 60 | 0730.300.991 | SNAP RING | 1; | |
| 70 | 0735.321.529 | NEEDLE CAGE | 1; | |
| 80 | 1346.304.187 | Косозубое колесо | 1; | |
| 90 | 1346.304.198 | Упорная шайба | 1; | |
| 90 | 0501.322.939 | THRUST WASHER | 1; | |
| 100 | 0735.295.239 | INNNER RING | 1; | |
| 110 | 0735.321.529 | NEEDLE CAGE | 1; | |
| 120 | 1346.304.167 | HELICAL GEAR | 1; | |
| 130 | 1308.304.087 | SLIDING SLEEVE | 1; | |
| 140 | 1346.304.177 | CLUTCH BODY | 1; | |
| 150 | 0735.330.799 | BALL BEARING | 1; | |
| 190 | 1346.304.186 | Фланец вала отбора мощности | 1; | |
| 200 | 0636.100.541 | HEXAGON BOLT | 1; | |
| 200 | 0730.113.920 | WASHER | 1; | |
| 250 | 0750.115.567 | NEEDLE CAGE | 1; | |
| 260 | 1346.304.136 | HELICAL GEAR | 1; | |
| 270 | 1346.304.094 | CLUTCH BODY | 1; | |
| 280 | 1346.204.005 | SYNCHRONIZER | 1; | |
| 280.10 | 1346.304.025 | SYNCHROBODY | 1; | |
| 280.20 | 1310.304.195 | SLIDING SLEEVE | 1; | |
| 280.30 | 1268.304.594 | SYNCHRORING | 2; | |
| 280.40 | 1297.304.436 | PRESSURE PIECE | 3; | |
| 280.60 | 0732.040.409 | COMPRSPRING | 3; | |
| 290 | 0730.302.358 | Кольцо пружинное стопорное | 1; | |
| 300 | 1346.304.093 | CLUTCH BODY | 1; | |
| 310 | 0750.115.566 | NEEDLE CAGE | 1; | |
| 320 | 1346.304.099 | HELICAL GEAR | 1; | |
| 330 | Шайба | Шайба | 1; | |
| 330 | 1346.304.199 | Шайба упорная | 1; | |
| 330 | 0501.323.702 | THRUST WASHER | 1; | |
| 340 | 0730.300.992 | SNAP RING | 1; | |
| 350 | 0750.115.565 | NEEDLE CAGE | 1; | |
| 360 | 1346.304.048 | HELICAL GEAR | 1; | |
| 370 | 1346.304.047 | CLUTCH BODY | 1; | |
| 380 | 1346.204.004 | SYNCHRONIZER | 1; | |
| 380.10 | 1346.304.118 | SYNCHROBODY | 1; | |
| 380.20 | 1333.304.061 | SLIDING SLEEVE | 1; | |
| 380.30 | 1317.304.150 | SYNCHRORING | 2; | |
| 380.40 | 1317.304.081 | PRESSURE PIECE | 3; | |
| 380.60 | 0732.042.510 | COMPRSPRING | 3; | |
| 390 | 0630.531.050 | RETAINING RING | 1; | |
| 400 | 0735.295.223 | INNNER RING | 1; | |
| 410 | 0735.358.346 | ROLLER CAGE | 1; | |
| 430 | 0630.513.070 | SNAP RING | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
