GEARBOX HOUSING 0091101215, 0091101216
/ ZF КПП ZF 8S-1350
010
010
012
012
020
030
030
042
042
050
050
058
058
064
064
070.010
070.020
090
090
110
110
120
130
140.010
140.020
160
180
190
200
210
220
230
234
240
240
250
260
270
270
310
312
480.010
480.020
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 010 | 0091301136 | Housing I | 1; | |
| 012 | 0736303005 | Screw plug | 1; | |
| 020 | 1313301038 | Gasket | 1; | |
| 030 | 0091301135 | Housing II | 1; | |
| 042 | 0636010172 | Hexagon screw | 2; | |
| 050 | 0636010172 | Hexagon screw | 6; | |
| 058 | 0636010205 | Hex cap screw | 13; | |
| 064 | 0636010205 | Hex cap screw | 2; | |
| 070.010 | 0501398755 | Magnetic screw plug | 1; | |
| 070.020 | 0634801321 | Sealing ring | 1; | |
| 090 | 0736303005 | Screw plug | 1; | |
| 110 | 0736303005 | Screw plug | 1; | |
| 120 | 0501308398 | Filter | 1; | |
| 130 | 0091201038 | Spray tube | 1; | |
| 140.010 | 0636302045 | Пробка с резьбой | 1; | |
| 140.020 | 0634801074 | Sealing ring | 1; | |
| 160 | 0750118153 | Roller bearing | 1; | |
| 170.010 | 0630502143 | Retaining ring | 1; | |
| 170.020 | 0630502161 | Retaining ring | 1; | |
| 170.030 | 0630502162 | Retaining ring | 1; | |
| 170.040 | 0630502163 | Retaining ring | 1; | |
| 170.050 | 0630502164 | Retaining ring | 1; | |
| 170.060 | 0630502165 | Retaining ring | 1; | |
| 170.070 | 0630502213 | Retaining ring | 1; | |
| 180 | 1295304129 | Oil coll.plate | 1; | |
| 190 | 0731201459 | Cylinder pin | 2; | |
| 200 | 0091305014 | Spur gear reverse | 1; | |
| 210 | 0750115011 | Needle cage | 2; | |
| 220 | 0730150064 | Thrust washer | 1; | |
| 230 | 1295305056 | Reverse idler shaft | 1; | |
| 234 | 1295305057 | Washer | 1; | |
| 240 | 0501308588 | Hex cap screw | 1; | |
| 250 | 0091307299 | Type plate | 1; | |
| 260 | 0501398460 | Blind rivet | 4; | |
| 270 | 0732612001 | Breather | 1; | |
| 310 | 0091301114 | Support plate gear shift | 1; | |
| 312 | 0636015264 | Hex cap screw | 1; | |
| 480.010 | 0636302045 | Пробка с резьбой | 1; | |
| 480.020 | 0634801074 | Sealing ring | 1; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
