Коробка передач ZF S5-42 для техники Камского автозавода
/ ZF КПП ZF S5-42 для КамАЗ

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
10
20
30
50
60
60
60
60
60
60
60
60
60
60
60
60
60
80
90
100
100
122
150
160
160
200
210
214
230
240
240
240
240
240
240
240
240
240
240
240
240
240
260
270
274
280
290
310
320
324
340
350
350
350
350
350
380
10110
10110
10110
10120
10120
10130
10130
10130
10140
10140
10140
10150
10150
10150
10160
10160
10160
10170
10170
10170
Поз. Артикул Название детали Кол-во
10 1307.304.623 MAIN SHAFT 1;
20 0735.320.873 NEEDLE CAGE 1;
30 1307.304.649 HELICAL GEAR 1;
50 1307.204.293 SYNCHRONIZER 1;
60 0730.501.314 RETAINING RING 1;
60 0730.501.544 RETAINING RING 1;
60 0730.501.299 RETAINING RING 1;
60 0730.501.543 RETAINING RING 1;
60 0730.501.541 RETAINING RING 1;
60 0730.501.265 RETAINING RING 1;
60 0730.501.540 RETAINING RING 1;
60 0730.501.264 RETAINING RING 1;
60 0730.501.506 RETAINING RING 1;
60 0730.501.405 RETAINING RING 1;
60 0730.501.406 RETAINING RING 1;
60 0730.501.542 RETAINING RING 1;
60 0730.501.407 RETAINING RING 1;
80 0735.321.010 NEEDLE CAGE 1;
90 1307.204.323 HELICAL GEAR 1;
100 1307.204.056 TAROLLBEARING 1;
100 1307.204.275 TAROLLBEARING 1;
122 1307.304.592 PULSE DISC 1;
150 1307.304.602 OUTPUT FLANGE 1;
160 1317.304.117 LOCKING NUT 1;
160 NUTM24x1,5 LOCKING NUT 1;
200 0735.320.873 NEEDLE CAGE 1;
210 1307.304.652 HELICAL GEAR 1;
214 1307.304.628 CLUTCH BODY 1;
230 1307.204.266 SYNCHRONIZER 1;
240 0730.501.314 RETAINING RING 1;
240 0730.501.299 RETAINING RING 1;
240 0730.501.506 RETAINING RING 1;
240 0730.501.405 RETAINING RING 1;
240 0730.501.406 RETAINING RING 1;
240 0730.501.264 RETAINING RING 1;
240 0730.501.540 RETAINING RING 1;
240 0730.501.542 RETAINING RING 1;
240 0730.501.543 RETAINING RING 1;
240 0730.501.541 RETAINING RING 1;
240 0730.501.265 RETAINING RING 1;
240 0730.501.407 RETAINING RING 1;
240 0730.501.544 RETAINING RING 1;
260 0735.320.871 NEEDLE CAGE 1;
270 1307.304.632 HELICAL GEAR 1;
274 1307.304.628 CLUTCH BODY 1;
280 0730.106.561 WASHER 1;
290 0730.162.428 BUSH 1;
310 0735.320.871 NEEDLE CAGE 1;
320 1307.304.638 HELICAL GEAR 1;
324 1307.304.626 CLUTCH BODY 1;
340 1307.204.317 SYNCHRONIZER 1;
350 0730.501.260 RETAINING RING 1;
350 0730.501.261 RETAINING RING 1;
350 0730.501.262 RETAINING RING 1;
350 0730.501.301 RETAINING RING 1;
350 0730.501.300 RETAINING RING 1;
380 0750.117.251 TAROLLBEARING 1;
10110 1307.204.230 SYNCHROBODY 1;
10110 1307.304.607 SYNCHROBODY 1;
10110 1307.304.608 SYNCHROBODY 1;
10120 1307.304.182 SYNCHRORING 1;
10120 1307.304.644 SYNCHRORING 1;
10130 1307.304.643 SYNCHRORING 1;
10130 1307.304.644 SYNCHRORING 1;
10130 1307.304.182 SYNCHRORING 1;
10140 1307.304.669 SLIDING SLEEVE 1;
10140 1307.304.671 SLIDING SLEEVE 1;
10140 1307.304.668 SLIDING SLEEVE 1;
10150 0635.460.010 BALL 3;
10150 0635.460.010 BALL 3;
10150 0635.460.010 BALL 3;
10160 0732.041.571 COMPRSPRING 3;
10160 0732.041.571 COMPRSPRING 3;
10160 0732.041.571 COMPRSPRING 3;
10170 1307.304.156 PRESSURE PIECE 3;
10170 1307.304.156 PRESSURE PIECE 3;
10170 1307.304.156 PRESSURE PIECE 3;
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
