DRIVE 5849.104.016
/ ZF VG-2000-300

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: DRIVE 5849.104.016 / ZF VG-2000-300
10
18
30
40
50
60
70
80
90
100
110
110
120
130
130
130
130
130
130
130
130
130
140
150
160
170
200
201
230
260
270
271
272
280
290
300
310
330
340
350
360
370
380
400
410
420
430
440
450
460
460
470
480
490
500
Поз. Артикул Название детали Кол-во Цена
10 5841.300.243 Input shaft 1;
18 5841.300.558 Oil dam 1; -
30 5841.300.185 G.shift sleeve 1; -
40 5841.300.245 Input gear 1; -
50 5841.300.246 Input gear 1; -
60 5841.300.570 Bearing cover 1; -
70 0636.011.335 Болт 6-гранный 6; -
80 5841.300.551 Pot 1; -
90 5840.333.233 Shaft seal 1; -
100 5840.333.240 Shaft seal 1; -
110 5841.300.574 Keg.rollenlage 2; -
120 5841.300.195 Slotted nut 1; -
130 5841.300.600 Shim NB; -
130 5841.300.606 Shim NB; -
130 5841.300.605 Shim NB; -
130 5841.300.604 Shim NB; -
130 5841.300.603 Shim NB; -
130 5841.300.602 Shim NB; -
130 5841.300.601 Shim NB; -
130 5841.300.599 Shim NB; -
130 SHIMPLATE Shim plate 1; -
140 5841.300.178 Interm.plate 1; -
150 5838.300.286 Kernl verschluss 2; -
160 0631.329.064 Slot.pin 1; -
170 0635.460.011 Ball 1; -
200 5841.300.488 Housing 1; -
201 5841.300.620 Bearing housing 1; -
230 5841.300.490 Oil pump cover 1; -
260 5841.300.359 Gear 1; -
270 0635.460.022 Ball 1; -
271 5841.300.640 Cover 1; -
272 5841.300.360 Oelpump.zahnkr. 1; -
280 0636.101.418 Cap screw 2; -
290 0636.101.689 Cap screw 2; -
300 5841.300.227 Cover 1; -
310 0636.011.607 Hexagon screw 6; -
330 0636.016.192 Hexagon screw 4; -
340 0637.842.535 Socket 1; -
350 0634.801.045 Sealing ring 1; -
360 5841.300.491 Hollow/union screw 1; -
370 5841.300.233 Oil induction pipe 1; -
380 0634.801.057 Sealing ring 1; -
400 0637.822.527 Union nut 1; -
410 5840.333.115 Socket 1; -
420 5840.333.112 Hexagon nut 1; -
430 5840.333.110 Union nut 1; -
440 5840.333.139 Sealing ring 1; -
450 5840.333.111 Pressure ring 1; -
460 5840.333.113 Cutting ring 2; -
470 0634.801.074 Sealing ring 1; -
480 0636.305.061 Screw plug 1; -
490 0634.801.033 Sealing ring 1 ; -
500 0636.305.072 Screw plug 1 ; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
