HOUSING 5844.101.001
/ ZF VG-2000-300
10
20
30
40
50
60
70
80
90
100
110
110
120
130
140
150
160
170
180
190
200
210
230
240
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 10 | 5841.300.011 | P.TO. Housing | 1; | |
| 20 | 5841.300.528 | Hinter.nebenantr. | 1; | |
| 30 | 0636.015.299 | Болт 6-гранный | 2; | |
| 40 | 0631.302.050 | Cylindrical pin | 2; | |
| 50 | 0635.332.038 | Ball bearing | 1; | |
| 60 | 0630.502.040 | Circlip | 1; | |
| 70 | 5841.300.529 | Output shaft | 1; | |
| 80 | 5841.300.643 | Needle cage | 1; | |
| 90 | 5841.300.027 | Gear shift sleeve | 1; | |
| 100 | 5841.300.472 | Gear shift fork | 1; | |
| 110 | 0630.501.014 | Retaining ring | 2; | |
| 120 | 0634.306.012 | O-ring | 1; | |
| 130 | 5841.300.375 | Piston | 1; | |
| 140 | 5841.300.652 | Sealing collar | 1; | |
| 150 | 5841.300.653 | Compr.spring | 1; | |
| 160 | 5841.300.647 | Formed tube | 1; | |
| 170 | 5841.300.373 | Bush | 1; | |
| 180 | 5841.300.374 | Washer | 1; | |
| 190 | 0630.502.029 | Circlip | 1; | |
| 200 | 0634.801.057 | Sealing ring | 1; | |
| 210 | 5840.333.259 | Shaft seal | 1; | |
| 230 | 0636.011.212 | Hexagon screw | 4; | |
| 240 | 0636.302.021 | Пробка с резьбой | 1; |
