3724D-C0326 Cab wiring harness group
/ DongFeng EQ4251W2 - 999Z
1
2
2
3
3
4
5
5
6
7
8
9
10
10
11
12
13
13
14
14
15
16
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| (51) -- Ground wire short circuit plug | (51) -- Ground wire short circuit plug | (51) -- Ground wire short circuit plug | ; | - | |
| (40)- To preheating switch | (40)- To preheating switch | (40)- To preheating switch | ; | - | |
| (38)- To left vehicle frame wiring harness | (38)- To left vehicle frame wiring harness | (38)- To left vehicle frame wiring harness | ; | - | |
| (36)- Ground wire short circuit plug 2 | (36)- Ground wire short circuit plug 2 | (36)- Ground wire short circuit plug 2 | ; | - | |
| (34)- To betweencenters differential switch | (34)- To betweencenters differential switch | (34)- To betweencenters differential switch | ; | - | |
| (32)- To ignition lock ON gear relay 2 | (32)- To ignition lock ON gear relay 2 | (32)- To ignition lock ON gear relay 2 | ; | - | |
| (30)- To rear fog lamp switch relay | (30)- To rear fog lamp switch relay | (30)- To rear fog lamp switch relay | ; | - | |
| (28)- To ACC gear relay | (28)- To ACC gear relay | (28)- To ACC gear relay | ; | - | |
| (26)- To left steering foot lamp relay | (26)- To left steering foot lamp relay | (26)- To left steering foot lamp relay | ; | - | |
| (57)- Wiper relay accessory | (57)- Wiper relay accessory | (57)- Wiper relay accessory | ; | - | |
| (55)- Low gear detector switch relay | (55)- Low gear detector switch relay | (55)- Low gear detector switch relay | ; | - | |
| (53) - Gang relay 2 | (53) - Gang relay 2 | (53) - Gang relay 2 | ; | - | |
| (42)- To ABS electrical control unit | (42)- To ABS electrical control unit | (42)- To ABS electrical control unit | ; | - | |
| (49)- To air conditioner heater wiring harness | (49)- To air conditioner heater wiring harness | (49)- To air conditioner heater wiring harness | ; | - | |
| (47)- To right door wiring harness | (47)- To right door wiring harness | (47)- To right door wiring harness | ; | - | |
| (45) - Earth | (45) - Earth | (45) - Earth | ; | - | |
| (43)- Electrical control system diagnostics interface | (43)- Electrical control system diagnostics interface | (43)- Electrical control system diagnostics interface | ; | - | |
| (41)- To right lower floor wiring harness | (41)- To right lower floor wiring harness | (41)- To right lower floor wiring harness | ; | - | |
| (39)- To radio and tape player | (39)- To radio and tape player | (39)- To radio and tape player | ; | - | |
| (37)- To front wall wiring harness | (37)- To front wall wiring harness | (37)- To front wall wiring harness | ; | - | |
| (35)- To fuse box | (35)- To fuse box | (35)- To fuse box | ; | - | |
| (33)- To front fog lamp relay | (33)- To front fog lamp relay | (33)- To front fog lamp relay | ; | - | |
| (31)- To small light relay | (31)- To small light relay | (31)- To small light relay | ; | - | |
| (29)- To ignition lock ON gear relay 1 | (29)- To ignition lock ON gear relay 1 | (29)- To ignition lock ON gear relay 1 | ; | - | |
| (63)- To speed changer controller | (63)- To speed changer controller | (63)- To speed changer controller | ; | - | |
| (71)- To preheating controller | (71)- To preheating controller | (71)- To preheating controller | ; | - | |
| (70)- To high beam relay | (70)- To high beam relay | (70)- To high beam relay | ; | - | |
| (68)- To working lamp socket | (68)- To working lamp socket | (68)- To working lamp socket | ; | - | |
| (66)- To combined meter | (66)- To combined meter | (66)- To combined meter | ; | - | |
| (64)- To trailer ABS | (64)- To trailer ABS | (64)- To trailer ABS | ; | - | |
| (62)- To multifunction buzzer | (62)- To multifunction buzzer | (62)- To multifunction buzzer | ; | - | |
| (60)- To left vehicle body main wiring harness | (60)- To left vehicle body main wiring harness | (60)- To left vehicle body main wiring harness | ; | - | |
| (71)- To low beam relay | (71)- To low beam relay | (71)- To low beam relay | ; | - | |
| (69)- To horn relay | (69)- To horn relay | (69)- To horn relay | ; | - | |
| (67)- To travel recording meter | (67)- To travel recording meter | (67)- To travel recording meter | ; | - | |
| (65) - Earth | (65) - Earth | (65) - Earth | ; | - | |
| (27)- To right steering foot lamp relay | (27)- To right steering foot lamp relay | (27)- To right steering foot lamp relay | ; | - | |
| (61)- To wiper intermittent relay | (61)- To wiper intermittent relay | (61)- To wiper intermittent relay | ; | - | |
| (59)- Compressor accessory relay | (59)- Compressor accessory relay | (59)- Compressor accessory relay | ; | - | |
| (58)- SPL gear selecting switch relay | (58)- SPL gear selecting switch relay | (58)- SPL gear selecting switch relay | ; | - | |
| (56)- Heater accessory relay | (56)- Heater accessory relay | (56)- Heater accessory relay | ; | - | |
| (54) - Gang relay 1 | (54) - Gang relay 1 | (54) - Gang relay 1 | ; | - | |
| (52)- DBR relay | (52)- DBR relay | (52)- DBR relay | ; | - | |
| (50) To right vehicle frame wiring harness | (50) To right vehicle frame wiring harness | (50) To right vehicle frame wiring harness | ; | - | |
| (48)- To timing relay (for engine produced by Yuchai only) | (48)- To timing relay (for engine produced by Yuchai only) | (48)- To timing relay (for engine produced by Yuchai only) | ; | - | |
| (46)- To engine wiring harness | (46)- To engine wiring harness | (46)- To engine wiring harness | ; | - | |
| (44)- To wiper motor | (44)- To wiper motor | (44)- To wiper motor | ; | - | |
| (25)- To ABS flashing code diagnosis switch | (25)- To ABS flashing code diagnosis switch | (25)- To ABS flashing code diagnosis switch | ; | - | |
| Q174B0616 | Q174B0616 | Болт | 1; | - | |
| Q41106 | Q41106 | Шайба | 1; | - | |
| 3724414-C0100 | 3724414-C0100 | Хомут крепления пучка проводов SMJ | 1; | - | |
| 3724414-C0100 | 3724414-C0100 | Хомут крепления пучка проводов SMJ | 2; | - | |
| 3724039-C0100 | 3724039-C0100 | Кронштейн соединителя | 1; | - | |
| (1) - Earth | (1) - Earth | (1) - Earth | ; | - | |
| (3)- To left door wiring harness | (3)- To left door wiring harness | (3)- To left door wiring harness | ; | - | |
| (5)- To front fog lamp switch | (5)- To front fog lamp switch | (5)- To front fog lamp switch | ; | - | |
| (7)- To rear fog lamp switch | (7)- To rear fog lamp switch | (7)- To rear fog lamp switch | ; | - | |
| (9)- To No.2 clutch switch | (9)- To No.2 clutch switch | (9)- To No.2 clutch switch | ; | - | |
| (11)- To stop lamp switch | (11)- To stop lamp switch | (11)- To stop lamp switch | ; | - | |
| (13)- To ignition lock | (13)- To ignition lock | (13)- To ignition lock | ; | - | |
| (15)- To wiring harness over floor | (15)- To wiring harness over floor | (15)- To wiring harness over floor | ; | - | |
| (17)- To flasher unit | (17)- To flasher unit | (17)- To flasher unit | ; | - | |
| (19) - Ground wire short circuit plug | (19) - Ground wire short circuit plug | (19) - Ground wire short circuit plug | ; | - | |
| (23)- To rear lamp switch | (23)- To rear lamp switch | (23)- To rear lamp switch | ; | - | |
| (2)- To left lower floor wiring harness | (2)- To left lower floor wiring harness | (2)- To left lower floor wiring harness | ; | - | |
| (4)- To ceiling wiring harness | (4)- To ceiling wiring harness | (4)- To ceiling wiring harness | ; | - | |
| (6)- To indoor dome light switch | (6)- To indoor dome light switch | (6)- To indoor dome light switch | ; | - | |
| (8)- To clutch switch | (8)- To clutch switch | (8)- To clutch switch | ; | - | |
| (10)- To hazard warning switch | (10)- To hazard warning switch | (10)- To hazard warning switch | ; | - | |
| (12) - to combined switch | (12) - to combined switch | (12) - to combined switch | ; | - | |
| (14) - to combined switch | (14) - to combined switch | (14) - to combined switch | ; | - | |
| (16)- To compositive alarm | (16)- To compositive alarm | (16)- To compositive alarm | ; | - | |
| (18)- To diode assembly | (18)- To diode assembly | (18)- To diode assembly | ; | - | |
| (21)- To cigarette lighter | (21)- To cigarette lighter | (21)- To cigarette lighter | ; | - | |
| (24)- To air horn switch | (24)- To air horn switch | (24)- To air horn switch | ; | - | |
| (22)- To dryer switch | (22)- To dryer switch | (22)- To dryer switch | ; | - | |
| (20)- To right vehicle body main wiring harness | (20)- To right vehicle body main wiring harness | (20)- To right vehicle body main wiring harness | ; | - | |
| 1 | 3724020-C0326 | Left Vehicle Body Main Wiring Harness Assembly | 1; | - | |
| 2 | 3724946-C0100 | Хомут | 1; | - | |
| 3 | Q1840620-Z6H | Болт | 2; | - | |
| 4 | 3724411-C0100 | Левая крышка кассеты SMJ (многофункциональный разъем) | 1; | - | |
| 5 | Q32206 | Гайка | 1; | - | |
| 6 | 3724410-C0100 | Левая крышка кассеты SMJ | 1; | - | |
| 7 | 3724030-C0326 | Right Vehicle Body Main Wiring Harness | 1; | - | |
| 8 | 3724420-C0100 | Левая кассета SMJ | 1; | - | |
| 9 | 3724421-C0100 | Левая крышка кассеты SMJ | 1; | - | |
| 10 | 3724922-C0100 | Хомут | 10; | - | |
| 11 | 3724023-C0100 | Защитный экран пучка проводов | 1; | - | |
| 12 | 3724022-C0100 | Защитный экран пучка проводов | 1; | - | |
| 13 | 3735100-C0100 | Блок реле | 2; | - | |
| 14 | 3722010-C0100 | Блок предохранителей | 2; | - | |
| 15 | 3724033-C0100 | Защитный экран пучка проводов | 1; | - | |
| 16 | 3724034-C0100 | Защитный экран пучка проводов | 2; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
