1S41893620711 Chassis harness
/ Foton 4189SLFKA-AEZA01
1
2
4
4
4
4
6
7
8
9
9
9
10
10
10
11
11
12
12
13
14
15
16
17
18
19
20
22
27
28
29
30
30
45
45
46
47
47
47
47
47
47
48
48
48
48
48
48
48
48
51
51
51
51
51
51
51
51
52
52
52
52
52
52
52
52
53
53
53
53
53
53
53
53
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1417035600190 | 1417035600190 | Cable tie | 110; | - | |
| 1S41893620711 | 1S41893620711 | Chassis harness | 1; | - | |
| 1 | H4362045011A0 | Harness, cross rail | 1; | - | |
| 2 | H4362040701A0 | Frame wire harness 1 | 1; | - | |
| 3 | Q32006 | Гайка шестигранная с зубчатым буртиком | 4; | - | |
| 4 | Q1460816 | Болт с шестигранной головкой, пружинная шайба и плоская шайба | 4; | - | |
| 5 | H4362053013A0 | Plastic foam combined bracket, harness | 1; | - | |
| 6 | H4362053015A0 | Bracket, harness, side rail | 1; | - | |
| 7 | H4362053024A0 | Bracket, harness, side rail | 1; | - | |
| 8 | H4362053007A0 | Bracket, harness, headlight | 1; | - | |
| 9 | H4362060002A0 | Engine ground wire | 1; | - | |
| 10 | 1B24937400019 | U Strip | 2; | - | |
| 11 | H4356023001A0 | Jacket, lintel | 1; | - | |
| 12 | H4362040027A0 | Frame wire harness 2 | 1; | - | |
| 13 | H4362010609A0 | Harness, engine | 1; | - | |
| 14 | H4362053005A0 | Tilt harness bracket | 2; | - | |
| 15 | H4362053028A0 | Bracket, harness, transmission | 1; | - | |
| 16 | Q150B1235 | Болт | 4; | - | |
| 17 | Q340B12 | Гайка крепления кронштейн нижней подножки | 5; | - | |
| 18 | Q40112 | Плоская шайба | 5; | - | |
| 19 | Q40312 | Шайба пружинная | 5; | - | |
| 20 | Q41212 | External serrated lock washer | 6; | - | |
| 21 | Q150B1040 | Болт | 1; | - | |
| 22 | H4362053008A0 | Bracket, harness, headlight | 1; | - | |
| 23 | H4362020001A0 | Power wire | 1; | - | |
| 24 | H4362020002A0 | Power wire | 1; | - | |
| 25 | H4362020003A0 | Power wire | 1; | - | |
| 26 | H4362020014A0 | Power wire | 1; | - | |
| 27 | H4362053010A0 | Bracket, after treatment harness | 1; | - | |
| 28 | H4362045002A0 | Turnover mechanism harness | 1; | - | |
| 29 | H4362053020A0 | Bracket, harness, cross rail | 1; | - | |
| 30 | Q1460820 | Болт с шестигранной головкой, пружинная шайба и плоская шайба | 2; | - | |
| 31 | H4362041003A0 | Socket, wire, trailer light | 1; | - | |
| 32 | Q1460825 | Болт с шестигранной головкой, пружинная шайба и плоская шайба | 2; | - | |
| 33 | Q340B08 | Гайка | 2; | - | |
| 34 | H4362070008A0 | Chassis main distribution box assembly | 1; | - | |
| 35 | H4362052012A0 | Bracket, main distribution box, chassis | 1; | - | |
| 36 | Q1460835 | Hexagon head bolt, spring washer and washer unit | 2; | - | |
| 37 | Q1460845 | Hexagon head bolt, spring washer and washer unit | 2; | - | |
| 38 | 1B24937171280 | Round head tie wrap | 8; | - | |
| 39 | 1324035600052 | Резиновая прокладка | 8; | - | |
| 40 | Q150B1240 | Болт крепления поводка стеклоочистителя | 1; | - | |
| 41 | 1417035600187 | Хомут ленточный | 90; | - | |
| 42 | 1331335600026 | Cable tie | 8; | - | |
| 43 | H4362080003A0 | Wire-threading sleeve | 3; | - | |
| 44 | 1417036181014 | Wire-threading sleeve I | 6; | - | |
| 45 | H4362080002A0 | Refractory cable tie | 4; | - | |
| 46 | H4362040039A0 | Gearbox harness | 1; | - | |
| 47 | H4362052001A0 | Bracket, harness, front axle | 8; | - | |
| 48 | Q150B1435 | Болт | 8; | - | |
| 49 | Q1841440TF2 | Hexagon flange bolt | 12; | - | |
| 50 | Q1841445TF2 | Hexagon flange bolt | 2; | - | |
| 51 | Q340B14 | Гайка | 8; | - | |
| 52 | Q40114 | Шайба плоская | 8; | - | |
| 53 | Q40314 | Шайба пружинная | 8; | - | |
| 54 | H4362053026A0 | Support, beam, power cord | 1; | - | |
| 55 | Q33014T13F2 | Hexagon flange self-locking nut | 14; | - | |
| 56 | H4362053004A0 | Bracket, harness, rear suspension | 1; | - | |
| 57 | H4362052027A0 | Bracket, harness, No. 1 cross rail | 2; | - | |
| 58 | H4362053022A0 | Bracket, harness, ABS solenoid valve, rear axle | 2; | - | |
| 59 | Q150B1025 | Болт | 2; | - | |
| 60 | Q340B10 | Гайка | 3; | 100 ₽ | |
| 61 | Q40110 | Плоская шайба | 3; | - | |
| 62 | Q40310 | Шайба пружинная | 3; | - | |
| 63 | H4362053021A0 | Bracket, harness, fuel sensor | 1; | - | |
| 64 | Q32008 | Гайка шестигранная с зубчатым буртиком | 2; | 240 ₽ | |
| 65 | Q32012 | Hexagon flange nut | 1; | - | |
| 66 | Q41210 | Стопорная шайба | 2; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
