1SB2483741903 Body harness
/ Foton 4189SLFKA-AEZA01

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: 1SB2483741903 Body harness / Foton 4189SLFKA-AEZA01
37
38
39
40
41
42
43
Поз. Артикул Название детали Кол-во Цена
1SB2483741903 1SB2483741903 Body harness 1; -
1 H4374010008A0 Harness, front wall 1; -
2 Q218B0820 Hexagon socket head bolt 4; -
3 Q2714832 Крестовой бочкообразный самонарезающий винт 8; -
4 H4374050009A0 Guard, interior central power distribution box 1; -
5 H4374050008A0 Central power distribution box 1; -
6 H4374050003A0 Mounting frame, harness, distribution box 1; -
7 H4374050001A0 Guard, harness, external central power distribution box, front wall 1; -
8 H4374200015A0 Adhesive sticker identification, relay and fuse 1; -
9 H4374010009A0 Vehicle body main harness 1; -
10 Q2204216 Cross recessed pan head tapping screw and washer seaming 10; -
11 H4374040013A0 Bracket, harness, door 1; -
12 1417035600187 Хомут ленточный 50; -
13 Q41206 Замковая шайба с внешними зубьями 4; -
14 Q40106 Плоская шайба 6; -
15 Q40306 Шайба пружинная 6; -
16 Q2204216F31 Cross recessed pan head tapping screw and washer seaming 2; -
17 1417035600190 Cable tie 15; -
18 H4374040002A0 Harness bracket 1 1; -
19 Q150B0616 Болт с шестигранной головкой 6; -
20 H4374040012A0 Bracket, main harness, body, tubular beam 1; -
21 H4374040004A0 Harness bracket 1; -
22 H4532020007A0 Plastic cotter pin 2; -
23 H4374040001A0 Guard, harness, door 1; -
24 H4374040003A0 Harness mounting bracket 1; -
25 H4374190001A0 OBD diagnostic switch assembly 1; -
26 Q32006 Гайка шестигранная с зубчатым буртиком 6; -
27 H4362053001A0 Mounting bracket, harness, frame, front wall 1; -
28 1331335600026 Cable tie 1; -
29 H4374100001A0 Harness, overhead file cabinet 1; -
30 H4374080002A0 Retaining clip, harness, post, door 2; -
31 H4374080001A0 Retaining clip, harness, post, door 2; -
32 H4374080003A0 Retaining clip, harness, door post 2; -
33 H4374080004A0 Fixing clip, harness 2; -
34 H4374040021A0 Bracket, harness, overhead file cabinet 2; -
35 Q2204213 Cross recessed pan head tapping screw and washer seaming 6; -
36 H4374040005A0 Bracket, harness, bottom plate 1; -
37 H4374110001A0 Left door wire harness 1; -
38 H4374120002A0 Right door wire harness 1; -
39 H4374150031A0 Harness, rear wall, cab 1; -
40 H4374190002A0 Block cover, threading hole, harness, controller 1; -
41 Q2203516 Tapping screw 2; -
42 Q2360616 Винт 2; -
43 1B24937400019 U Strip 5; -
44 H4513040003A0 Hole sticker 9; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
